Services | |
Type | IP-Sicherheitskamera |
transmission technology | Kabelgebunden |
Eigenschaft | Digest-Authentifizierung |
Dynamischer Bereich | 120 dB |
Design | |
form factor | Patrone (Form) |
attachment type | Zimmerdecke |
Product color | Grau |
housing material | Aluminium |
International degree of protection (IP code) | IP66 |
IK-Kodex | IK10 |
Camera | |
minimum lighting | 0,15 Lux |
viewing angle (horizontal) | 107.5° |
viewing angle (vertical) | 59.7° |
Lens viewing angle, diagonal | 122° |
white balance | ATW, AWC, Drinnen, Manuell, Draußen |
Verschlusstyp | Elektronisch |
camera shutter speed | 1/5 - 1/12000 s |
Anzahl der Bereiche zur Verdeckung der Privatsphäre | 6 |
image sensor | |
number of sensors | 1 |
Image sensor size | 25,4 / 3 mm (1 / 3") |
Sensor-Typ | CMOS |
lens | |
number of lenses | 1 |
distance determination | 37,5 m |
Abstandsbeobachtung | 15 m |
Abstandserkennung | 7,5 m |
Maximum f-number | 2 |
Abstandsermittlung | 3,8 m |
Fixed focal length | 2,8 mm |
Naheinstellgrenze | 0,5 m |
night vision | |
night vision distance | 20 m |
LED Type | IR |
Video | |
Maximum resolution | 2560 x 1440 Pixel |
total megapixels | 4 MP |
Supported video formats | H.264, H.265, M-JPEG |
Supported graphic resolutions | 640 x 360, 640 x 480 (VGA), 720 x 480, 720 x 576, 800 x 448, 800 x 600 (SVGA), 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080) |
Up to 30 frames per second | 30 fps |
gain control type | Manuell |
Bitratenkontrolle | Konstante Bitrate (CBR), Variable Bitrate (VBR) |
Audio | |
Supported audio formats | ADPCM, G.711 μ-law, G.726 |
network | |
Ethernet interfaces type | Schnelles Ethernet |
mesh standard | IEEE 802.3af |
streaming method | Multicasting, Unicast |
storage medium | |
Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
Max memory card size | 128 GB |
Flash memory | 256 MB |
storage capacity | 512 MB |
connections and interfaces | |
Number of Ethernet LAN ports (RJ-45) | 1 |
safety | |
Supported security algorithms | EAP-LEAP, EAP-TLS |
alert notification type | E-Mail |
Intelligent Video Surveillance (IVS) system properties | Defokussieren, Erkennung Leitungskreuzungen, Erkennung des Eintritts in eine Region, Region exiting detection |
energy | |
energy source | Gleichstrom, PoE |
Power consumption (standard operation) | 6,8 W |
Power consumption (max.) | 9,1 W |
Power Consumption (Power over Ethernet (PoE)) | 10,7 W |
operating conditions | |
operating temperatur | -40 - 55 °C |
Storage temperature range | -40 - 60 °C |
weight and dimensions | |
broad | 75,2 mm |
depth | 255,4 mm |
height | 77,6 mm |
Weight | 700 g |
scope of delivery | |
number of cameras | 1 |
