| Services | |
| Type | IP-Sicherheitskamera |
| transmission technology | Kabelgebunden |
| Eigenschaft | IP-Adressen Filter |
| Design | |
| form factor | Dome |
| attachment type | Decke/Wand |
| Product color | Schwarz, Weiß |
| housing material | Aluminium |
| International degree of protection (IP code) | IP66 |
| IK-Kodex | IK10 |
| Camera | |
| rotation angle | 355° |
| viewing angle (horizontal) | 87.6° |
| viewing angle (vertical) | 46.4° |
| Lens viewing angle, diagonal | 104.5° |
| tilt angle range | 0 - 67° |
| swivel range | 0 - 350° |
| white balance | ATW, AWC, Drinnen, Manuell, Draußen |
| Verschlusstyp | Elektronisch |
| camera shutter speed | 1/5 - 1/12000 s |
| image sensor | |
| number of sensors | 1 |
| Image sensor size | 25,4 / 2,8 mm (1 / 2.8") |
| Sensor-Typ | CMOS |
| Number of Effective Pixels (H x V) | 1920 x 1080 Pixel |
| lens | |
| number of lenses | 1 |
| Maximum f-number | 1,6 |
| Fixed focal length | 4 mm |
| night vision | |
| night vision distance | 25 m |
| LED Type | IR |
| Video | |
| Maximum resolution | 1920 x 1080 Pixel |
| total megapixels | 2 MP |
| Video compression formats | H.264, H.265, M-JPEG |
| Supported graphic resolutions | 640 x 360, 640 x 480 (VGA), 720 x 480, 720 x 576, 800 x 448, 800 x 600 (SVGA), 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080) |
| Up to 30 frames per second | 30 fps |
| Bitratenkontrolle | Konstante Bitrate (CBR), Variable Bitrate (VBR) |
| Audio | |
| Supported audio formats | ADPCM, G.711, G.726 |
| Samplerate | 8 kHz |
| network | |
| Ethernet interfaces type | Schnelles Ethernet |
| mesh standard | IEEE 802.3af |
| number of users | 6 Benutzer |
| streaming method | Multicasting, Unicast |
| storage medium | |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Max memory card size | 128 GB |
| Flash memory | 256 MB |
| storage capacity | 512 MB |
| connections and interfaces | |
| Number of Ethernet LAN ports (RJ-45) | 1 |
| Composite video output | 1 |
| safety | |
| Supported security algorithms | EAP-LEAP, EAP-TLS |
| alert notification type | E-Mail |
| Intelligent Video Surveillance (IVS) system properties | Defokussieren |
| management functions | |
| Verhaltensanalyse | Erkennung Leitungskreuzungen |
| energy | |
| energy source | Gleichstrom, PoE |
| Power consumption (standard operation) | 5,1 W |
| Power consumption (max.) | 6,4 W |
| Power Consumption (Power over Ethernet (PoE)) | 7,4 W |
| operating conditions | |
| operating temperatur | -30 - 55 °C |
| Storage temperature range | -30 - 60 °C |
| Operating relative humidity | 0 - 90% |
| humidity during storage | 0 - 90% |
| system requirement | |
| Supports Windows operating systems | Windows 10, Windows 8.1 |
| Supports Mac operating systems | Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave |
| weight and dimensions | |
| broad | 120 mm |
| depth | 120 mm |
| height | 91,7 mm |
| Weight | 510 g |
| scope of delivery | |
| number of cameras | 1 |
