| Services | |
| Type | IP-Sicherheitskamera |
| Unterstützte Positionierung | Draußen |
| transmission technology | Kabelgebunden |
| Eigenschaft | Betriebsanleitung |
| number of languages | 17 |
| Design | |
| form factor | Dome |
| attachment type | Zimmerdecke |
| Product color | Weiß |
| housing material | Aluminium |
| International degree of protection (IP code) | IP66 |
| IK-Kodex | IK10 |
| Camera | |
| minimum lighting | 0 Lux |
| rotation angle | 350° |
| viewing angle (horizontal) | 98.6° |
| viewing angle (vertical) | 52.3° |
| Lens viewing angle, diagonal | 115.7° |
| tilt angle range | 0 - 67° |
| swivel range | 0 - 350° |
| white balance | ATW, AWC, Drinnen, Manuell, Draußen |
| Verschlusstyp | Elektronisch |
| camera shutter speed | 1/5 - 1/12000 s |
| image sensor | |
| number of sensors | 1 |
| Image sensor size | 25,4 / 3 mm (1 / 3") |
| Sensor-Typ | CMOS |
| lens | |
| number of lenses | 1 |
| Maximum f-number | 1,6 |
| Fixed focal length | 3,2 mm |
| Abstandsfeststellung (wide) | 27 m |
| Abstandsfeststellung (tele) | 129 m |
| Abstandsbeobachtung (wide) | 11 m |
| Abstandsbeobachtung (tele) | 52 m |
| Abstandserkennung (wide) | 6 m |
| Abstandserkennung (tele) | 26 m |
| Abstandsermittlung (wide) | 3 m |
| Abstandsermittlung (tele) | 13 m |
| night vision | |
| night vision distance | 30 m |
| LED Type | IR |
| Video | |
| Maximum resolution | 2560 x 1440 Pixel |
| total megapixels | 4 MP |
| Supported video formats | H.264, H.265, M-JPEG |
| Video compression formats | H.264, H.265, M-JPEG |
| Up to 30 frames per second | 30 fps |
| Bitratenkontrolle | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Audio | |
| Supported audio formats | ADPCM, G.711, G.726 |
| Samplerate | 8 kHz |
| voice codec | G.711ulaw, G.726, G.726-32 |
| network | |
| Ethernet interfaces type | Schnelles Ethernet |
| mesh standard | IEEE 802.3af |
| number of users | 6 Benutzer |
| streaming method | Multicasting, Unicast |
| storage medium | |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Max memory card size | 128 GB |
| Flash memory | 256 MB |
| storage capacity | 512 MB |
| connections and interfaces | |
| Number of Ethernet LAN ports (RJ-45) | 1 |
| Composite video output | 1 |
| safety | |
| Password protection type | Benutzer |
| Supported security algorithms | EAP-LEAP, EAP-TLS, HTTPS, LEAP |
| alert notification type | E-Mail |
| Intelligent Video Surveillance (IVS) system properties | Defokussieren |
| energy | |
| energy source | Gleichstrom, PoE |
| Power consumption (standard operation) | 7,2 W |
| Power consumption (max.) | 11,4 W |
| Power Consumption (Power over Ethernet (PoE)) | 8,5 W |
| DC output volts | 12 |
| operating conditions | |
| operating temperatur | -40 - 55 °C |
| Storage temperature range | -40 - 60 °C |
| Operating relative humidity | 0 - 95% |
| humidity during storage | 0 - 95% |
| weight and dimensions | |
| height | 106,1 mm |
| diameter | 13,7 cm |
| Weight | 710 g |
| scope of delivery | |
| number of cameras | 1 |
