| Services | |
| Type | IP-Sicherheitskamera |
| Unterstützte Positionierung | Innen & Außen |
| transmission technology | Kabelgebunden |
| Eigenschaft | HTTPS-Verschlüsselung |
| Dynamischer Bereich | 120 dB |
| Design | |
| form factor | Dome |
| attachment type | Zimmerdecke |
| Product color | Weiß |
| housing material | Aluminium, Kunststoff |
| International degree of protection (IP code) | IP66 |
| IK-Kodex | IK10 |
| Camera | |
| minimum lighting | 0 Lux |
| rotation angle | 355° |
| tilt angle range | 0 - 67° |
| swivel range | 0 - 350° |
| white balance | ATW, AWC, Drinnen, Manuell, Draußen |
| Verschlusstyp | Elektronisch |
| camera shutter speed | 1/5 ~ 1/12000 s |
| image sensor | |
| Image sensor size | 25,4 / 2,8 mm (1 / 2.8") |
| Sensor-Typ | CMOS |
| lens | |
| focal range | 3,3 - 10 mm |
| Naheinstellgrenze | 0,5 m |
| night vision | |
| night vision distance | 30 m |
| infrared wavelength | 850 nm |
| Video | |
| Maximum resolution | 2560 x 1440 Pixel |
| total megapixels | 4 MP |
| Video compression formats | H.264, H.265, M-JPEG |
| Up to 30 frames per second | 30 fps |
| noise canceling technology | Smart Super Noise Reduction (SSNR) |
| Bitratenkontrolle | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| network | |
| Ethernet interfaces type | Schnelles Ethernet |
| streaming method | Multicasting, Unicast |
| storage medium | |
| Compatible memory cards | MicroSD (TransFlash), SDHC, SDXC |
| Max memory card size | 128 GB |
| Flash memory | 256 MB |
| storage capacity | 512 MB |
| connections and interfaces | |
| Number of Ethernet LAN ports (RJ-45) | 1 |
| safety | |
| Supported security algorithms | EAP-LEAP, EAP-PEAP, EAP-TLS, MSCHAPv2 |
| energy | |
| energy source | PoE |
| Power consumption (standard operation) | 6 W |
| Power consumption (max.) | 8 W |
| operating conditions | |
| operating temperatur | -30 - 55 °C |
| Storage temperature range | -30 - 55 °C |
| Operating relative humidity | 0 - 95% |
| weight and dimensions | |
| diameter | 13,8 cm |
| Length (mm) | 107,1 mm |
| Weight | 550 g |
| scope of delivery | |
| number of cameras | 1 |
