| Services | |
| Type | IP-Sicherheitskamera |
| Unterstützte Positionierung | Draußen |
| transmission technology | Kabelgebunden |
| Eigenschaft | IP-Adressen Filter |
| Design | |
| form factor | Patrone (Form) |
| attachment type | Decke/Wand |
| Product color | Grau |
| housing material | Aluminium |
| International degree of protection (IP code) | IP66 |
| IK-Kodex | IK10 |
| Camera | |
| minimum lighting | 0 Lux |
| viewing angle (horizontal) | 113.7° |
| viewing angle (vertical) | 61° |
| Lens viewing angle, diagonal | 134.5° |
| white balance | ATW, AWC, Drinnen, Manuell, Draußen |
| image sensor | |
| Image sensor size | 25,4 / 2,8 mm (1 / 2.8") |
| Sensor-Typ | CMOS |
| Number of Effective Pixels (H x V) | 1920 x 1080 Pixel |
| lens | |
| number of lenses | 1 |
| Maximum f-number | 2 |
| Fixed focal length | 2,8 mm |
| night vision | |
| night vision distance | 20 m |
| LED Type | IR |
| Video | |
| Maximum resolution | 1920 x 1080 Pixel |
| total megapixels | 2 MP |
| Supported video formats | H.264, H.265 |
| Video compression formats | H.264, H.265 |
| Supported graphic resolutions | 640 x 360, 720 x 480, 800 x 448, 800 x 600 (SVGA), 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080) |
| Up to 30 frames per second | 30 fps |
| Audio | |
| voice codec | G.711, G.711u, G.726 |
| network | |
| Ethernet interfaces type | Schnelles Ethernet |
| mesh standard | IEEE 802.1af, IEEE 802.1x |
| number of users | 6 Benutzer |
| streaming method | Multicasting, Unicast |
| storage medium | |
| Compatible memory cards | SD, SDHC, SDXC |
| Max memory card size | 512 GB |
| Flash memory | 256 MB |
| storage capacity | 128 MB |
| connections and interfaces | |
| Number of Ethernet LAN ports (RJ-45) | 1 |
| safety | |
| Password protection type | Benutzer |
| Supported security algorithms | HTTPS, SNMPv2, SNMPv3, SSL/TLS |
| alert notification type | E-Mail |
| energy | |
| energy source | Gleichstrom, PoE |
| Power consumption (standard operation) | 4,5 W |
| Power consumption (max.) | 6 W |
| Power Consumption (Power over Ethernet (PoE)) | 7 W |
| DC output volts | 12 |
| operating conditions | |
| operating temperatur | -30 - 55 °C |
| Storage temperature range | -30 - 60 °C |
| Operating relative humidity | 0 - 90% |
| humidity during storage | 0 - 90% |
| system requirement | |
| Supports Windows operating systems | Windows 10, Windows 7, Windows 8 |
| Supports Mac operating systems | Mac OS X 10.11 El Capitan, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave |
| weight and dimensions | |
| height | 246 mm |
| diameter | 7 cm |
| Weight | 700 g |
| scope of delivery | |
| number of cameras | 1 |
