Form factor | Bullet |
Product colour | White |
International Protection (IP) code | IP67 |
Mounting Type | Wall |
Power source type | DC, PoE |
Power consumption (max) | 7.2 W |
DC output current | 0.6 A |
Power consumption (Power over Ethernet (PoE)) | 8.5 W |
DC output voltage | 12 |
Anti-flicker | Yes |
PASSWORD PROTECTION | Yes |
IP address filtering | Yes |
HTTPS encryption | Yes |
Active tampering alarm | Yes |
Motion sensor | Yes |
Mirror | Yes |
Heartbeat | Yes |
Storage relative humidity (H-H) | 0 - 95% |
Operating temperature (T-T) | -30 - 60 °C |
Operating relative humidity (H-H) | 0 - 95% |
Storage temperature (T-T) | -30 - 60 °C |
Reset button | Yes |
Behavior analysis | Intrusion detection, Line crossing detection, Region entrance detection, Region exiting detection |
Web browser | Yes |
Length | 215.2 mm |
PACKAGE WEIGHT | 1 kg |
Package height | 141 mm |
Package width | 137 mm |
Height | 78.6 mm |
Package depth | 315 mm |
Weight | 680 g |
Width | 78.8 mm |
Ethernet LAN | Yes |
Ethernet interface type | Fast Ethernet |
Networking standards | IEEE 802.3af |
Bluetooth | No |
Wi-Fi | No |
Number of users | 32 user(s) |
Certification | Class BFCC SDoC (47 CFR Part 15, Subpart B);CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014);RCM (AS/NZS CISPR 32: 2015);IC VoC (ICES-003: Issue 6, 2016);KC (KN 32: 2015, KN 35: 2015)UL (UL 60950-1);CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014);CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014);BIS (IS 13252(Part 1):2010+A1:2013+A2:2015);LOA (IEC/EN 60950-1)CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)Reach Regulation (EC) No 1907/2006 |
Wide Dynamic Range (WDR) | Yes |
Connectivity Technology | Wired |
Type | IP security camera |
Placement supported | Outdoor |
Languages support | Multi |
Day/night mode | Yes |
Number of languages | 33 |
Number of Cameras | 1 |
Signal-to-Noise Ratio (SNR) | 120 dB |
COMPATIBLE MEMORY CARDS | MicroSDHC |
Card reader integrated | Yes |
Built-in HDD | No |
Maximum memory card size | 256 GB |
Ethernet LAN (RJ-45) ports | 1 |
Viewing angle, horizontal | 107° |
Angle of rotation | 360° |
Camera shutter speed | 1/3 - 1/100000 s |
Tilt angle range | 0 - 90° |
Pan range | 0 - 360° |
Viewing angle, vertical | 56° |
Camera tilt control | Yes |
Viewing angle, diagonal | 127° |
Camera pan control | Yes |
Optical sensor size | 25.4 / 2.8 mm (1 / 2.8") |
Progressive Scan | Yes |
Sensor type | CMOS |
Number of sensors | 1 |
Maximum Resolution | 1920 x 1080 pixels |
Video formats supported | H.264+ |
Noise reduction | Yes |
Supported graphics resolutions | 640 x 480 (VGA) |
Highlight Compensation (HLC) | Yes |
Bit rate | 32 Kbps - 8 Mbps |
Back Light Compensation (BLC) | Yes |
Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
Supported video modes | 360p |
Total megapixels | 2 MP |
Frame rate | 30 fps |
Privacy masking | Yes |
Gain control type | Auto |
Video compression formats | H.265 |
Region of Interest (ROI) encoding | Yes |
Noise reduction technology | 3D noise reduction |
Image quality adjustment | Brightness |
Video streaming | Yes |
Night Vision | Yes |
Fixed focal length | 2.8 mm |
Maximum aperture number | 1 |
Number of lenses | 1 |
