Form factor | Dome |
International Protection (IP) code | IP67 |
Protection features | Dust resistant |
Product colour | White |
Housing material | Aluminium |
Mounting Type | Ceiling/wall |
Power consumption (max) | 6 W |
Power source type | DC, PoE |
DC output voltage | 12 |
Power consumption (Power over Ethernet (PoE)) | 7 W |
Mirror | Yes |
Active tampering alarm | Yes |
Heartbeat | Yes |
Anti-flicker | Yes |
IP address filtering | Yes |
Video motion detection | Yes |
HTTPS encryption | Yes |
PASSWORD PROTECTION | Yes |
Storage relative humidity (H-H) | 0 - 95% |
Operating relative humidity (H-H) | 0 - 95% |
Operating temperature (T-T) | -30 - 60 °C |
Storage temperature (T-T) | -30 - 60 °C |
Reset button | Yes |
Behavior analysis | Intrusion detection, Line crossing detection, Region entrance detection, Region exiting detection |
Web browser | Yes |
Package depth | 170 mm |
Package width | 170 mm |
Weight | 700 g |
PACKAGE WEIGHT | 995 g |
Height | 125.2 mm |
Package height | 150 mm |
Diameter | 13.8 cm |
Wi-Fi | No |
Ethernet LAN | Yes |
Networking standards | IEEE 802.3af |
Ethernet interface type | Fast Ethernet |
Bluetooth | No |
Number of users | 32 user(s) |
Connectivity Technology | Wired |
Type | IP security camera |
Wide Dynamic Range (WDR) | Yes |
Placement supported | Outdoor |
Number of languages | 33 |
Day/night mode | Yes |
Languages support | Multi |
Number of Cameras | 1 |
Signal-to-Noise Ratio (SNR) | 120 dB |
COMPATIBLE MEMORY CARDS | MicroSDHC |
Card reader integrated | Yes |
Maximum memory card size | 256 GB |
Ethernet LAN (RJ-45) ports | 1 |
Tilt angle range | 0 - 75° |
Camera shutter speed | 1/3 - 1/100000 s |
Angle of rotation | 360° |
Pan range | 0 - 360° |
Lens viewing angle, vertical | 56° |
Camera pan control | Yes |
Camera tilt control | Yes |
Lens viewing angle, horizontal | 107° |
Lens viewing angle, diagonal | 127° |
Optical sensor size | 25.4 / 2.8 mm (1 / 2.8") |
Progressive Scan | Yes |
Number of sensors | 1 |
Sensor type | CMOS |
Supported graphics resolutions | 1920 x 1080 (HD 1080) |
Maximum Resolution | 1920 x 1080 pixels |
Supported video modes | 240p |
Noise reduction technology | 3D noise reduction |
Video formats supported | H.264 |
Highlight Compensation (HLC) | Yes |
Noise reduction | Yes |
Back Light Compensation (BLC) | Yes |
Total megapixels | 2 MP |
Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
Region of Interest (ROI) encoding | Yes |
Bit rate | 32 Kbps - 8 Mbps |
Frame rate | 30 fps |
Gain control type | Auto |
Video compression formats | H.264+ |
Image quality adjustment | Saturation |
Video streaming | Yes |
Privacy masking | Yes |
Night vision distance | 30 m |
Night Vision | Yes |
Maximum aperture number | 1 |
Fixed focal length | 2.8 mm |
Number of lenses | 1 |
