Mounting Type | Ceiling/wall |
International Protection (IP) code | IP67 |
Product colour | White |
Housing material | Aluminium |
Form factor | Dome |
I code | IK08 |
Power consumption (Power over Ethernet (PoE)) | 8 W |
DC output voltage | 12 |
Power source type | DC, PoE |
Power consumption (max) | 6.5 W |
Video motion detection | Yes |
Anti-flicker | Yes |
Heartbeat | Yes |
PASSWORD PROTECTION | Yes |
HTTPS encryption | Yes |
IP address filtering | Yes |
Operating relative humidity (H-H) | 0 - 95% |
Storage relative humidity (H-H) | 0 - 95% |
Storage temperature (T-T) | -30 - 60 °C |
Operating temperature (T-T) | -30 - 60 °C |
Behavior analysis | Intrusion detection, Line crossing detection |
Web-based management | Yes |
Reset button | Yes |
PACKAGE WEIGHT | 635 g |
Package depth | 134 mm |
Package width | 134 mm |
Weight | 400 g |
Height | 72.6 mm |
Package height | 108 mm |
Number of users | 32 user(s) |
Networking standards | IEEE 802.1x |
Ethernet interface type | Fast Ethernet |
Bluetooth | No |
Wi-Fi | No |
Ethernet LAN | Yes |
Quality of Service (QoS) support | Yes |
Alarm input/output | Yes |
Placement supported | Outdoor |
Infrared (IR) cut-off filter | Yes |
Number of languages | 33 |
Day/night mode | Yes |
Wide Dynamic Range (WDR) | Yes |
Connectivity Technology | Wired |
Type | IP security camera |
Number of Cameras | 1 |
Sample Rate | 48 kHz |
Audio input channels | 1 channels |
Voice Codecs | G.722.1 |
Audio output channels | 1 channels |
COMPATIBLE MEMORY CARDS | MicroSDHC |
Built-in HDD | No |
Card reader integrated | Yes |
Maximum memory card size | 256 GB |
Ethernet LAN (RJ-45) ports | 1 |
Camera tilt control | Yes |
Camera pan control | Yes |
Angle of rotation | 360° |
Lens viewing angle, horizontal | 112° |
Lens viewing angle, vertical | 61° |
Tilt angle range | 0 - 75° |
Camera shutter speed | 1/3 - 1/100000 s |
Pan range | -30 - 30° |
Number of sensors | 1 |
Sensor type | CMOS |
Progressive Scan | Yes |
Optical sensor size | 25.4 / 1.8 mm (1 / 1.8") |
Gain control type | Auto |
Image quality adjustment | Sharpness |
Privacy masking | Yes |
Video streaming | Yes |
Video compression formats | H.265+ |
Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
Noise reduction | Yes |
Maximum Resolution | 2688 x 1520 pixels |
Bit rate | 32 Kbps - 8 Mbps |
Total megapixels | 4 MP |
Highlight Compensation (HLC) | Yes |
Back Light Compensation (BLC) | Yes |
Region of Interest (ROI) encoding | Yes |
Noise reduction technology | 3D noise reduction |
Frame rate | 30 fps |
Night Vision | Yes |
Night vision distance | 30 m |
Number of lenses | 1 |
Identify distance | 6 m |
Detect distance | 58 m |
Recognize distance | 11 m |
Observe distance | 23 m |
Fixed focal length | 2.8 mm |
