| Lens mount interface | M12 |
| International Protection (IP) code | IP67 |
| Product colour | White |
| Housing material | Metal |
| Form factor | Dome |
| Protection features | Water resistant |
| Mounting Type | Ceiling/wall |
| Power consumption (max) | 6 W |
| Power source type | DC, PoE |
| Power consumption (Power over Ethernet (PoE)) | 7.5 W |
| DC output voltage | 12 |
| DC output current | 0.5 A |
| Security algorithms | EAP-MD5 |
| Audit log | Yes |
| IP address filtering | Yes |
| Active tampering alarm | Yes |
| Password reset via email | Yes |
| Human and vehicle targets classification | Yes |
| Privacy protection | Yes |
| PASSWORD PROTECTION | Yes |
| HTTPS encryption | Yes |
| Video motion detection | Yes |
| Digest authentication | Yes |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage temperature (T-T) | -30 - 60 °C |
| Operating temperature (T-T) | -30 - 60 °C |
| Storage relative humidity (H-H) | 0 - 95% |
| Reset button | Yes |
| Web-based management | Yes |
| Behavior analysis | Intrusion detection, Line crossing detection |
| Height | 95.9 mm |
| Diameter | 12.7 cm |
| Weight | 600 g |
| Wi-Fi | No |
| Bluetooth | No |
| Ethernet interface type | Fast Ethernet |
| Ethernet LAN | Yes |
| Networking standards | IEEE 802.3af |
| Live view | Yes |
| Number of users | 32 user(s) |
| User access level | Administrator, Operator, User |
| Number of simultaneous live view channels | 6 channels |
| Type | IP security camera |
| Connectivity Technology | Wired |
| Wide Dynamic Range (WDR) | Yes |
| Dynamic range | 120 dB |
| Number of languages | 33 |
| Day/night mode | Yes |
| Placement supported | Outdoor |
| Infrared (IR) cut-off filter | Yes |
| Languages support | Multi |
| Package width | 150 mm |
| Package height | 141 mm |
| Package depth | 150 mm |
| PACKAGE WEIGHT | 909 g |
| Number of Cameras | 1 |
| Built-in microphone | No |
| Card reader integrated | Yes |
| COMPATIBLE MEMORY CARDS | MicroSD (TransFlash) |
| Maximum memory card size | 512 GB |
| Built-in HDD | No |
| Ethernet LAN (RJ-45) ports | 1 |
| Minimum illumination | 0 lx |
| Tilt angle range | 0 - 75° |
| Angle of rotation | 360° |
| Lens viewing angle, vertical | 57° |
| Camera shutter speed | 1/3 - 1/100000 s |
| Lens viewing angle, horizontal | 107° |
| Lens viewing angle, diagonal | 128° |
| Pan range | 0 - 360° |
| Browser supported | IE 10, IE 11, Chrome 57.0+, Firefox 52.0+ |
| Progressive Scan | Yes |
| Optical sensor size | 25.4 / 2.8 mm (1 / 2.8") |
| Sensor type | CMOS |
| Highlight Compensation (HLC) | Yes |
| Back Light Compensation (BLC) | Yes |
| Bit rate | 32 Kbps - 16 Mbps |
| Total megapixels | 6 MP |
| Supported graphics resolutions | 640 x 360 |
| Maximum Resolution | 3200 x 1800 pixels |
| Video compression formats | H.265+ |
| Noise reduction technology | 3D noise reduction |
| Video recording | Yes |
| Image quality adjustment | Saturation |
| Frame rate | 30 fps |
| Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Noise reduction | Yes |
| Video streaming | Yes |
| LED type | IR |
| Night vision distance | 30 m |
| Night Vision | Yes |
| Infra-red wavelength | 850 nm |
| Fixed focal length | 2.8 mm |
| Compliance certificates | RoHS |
