Mounting Type | Ceiling/wall |
Form factor | Dome |
International Protection (IP) code | IP67 |
Housing material | Metal |
I code | IK10 |
Product colour | Black |
Power consumption (Power over Ethernet (PoE)) | 12.5 W |
DC output voltage | 12 |
Power source type | DC, PoE |
Power consumption (max) | 10.5 W |
PASSWORD PROTECTION | Yes |
IP address filtering | Yes |
HTTPS encryption | Yes |
Intelligent Video Surveillance (IVS) system features | Face detection |
Mirror | Yes |
Security algorithms | TLS |
Operating temperature (T-T) | -30 - 60 °C |
Operating relative humidity (H-H) | 0 - 95% |
Storage temperature (T-T) | -30 - 60 °C |
Storage relative humidity (H-H) | 0 - 95% |
Behavior analysis | Intrusion detection, Line crossing detection |
Reset button | Yes |
Web-based management | Yes |
Package height | 173 mm |
Package width | 244 mm |
Package depth | 174 mm |
Height | 111.6 mm |
Weight | 880 g |
Number of users | 32 user(s) |
Ethernet LAN | Yes |
Ethernet interface type | Fast Ethernet |
Wi-Fi | No |
Quality of Service (QoS) support | Yes |
Networking standards | IEEE 802.3af |
Bluetooth | No |
Placement supported | Outdoor |
Infrared (IR) cut-off filter | Yes |
Type | IP security camera |
Number of languages | 33 |
Languages support | Korean |
Wide Dynamic Range (WDR) | Yes |
Day/night mode | Yes |
Connectivity Technology | Wired |
Number of Cameras | 1 |
Voice Codecs | AAC |
Audio formats supported | MP3 |
Sample Rate | 48 kHz |
Maximum memory card size | 256 GB |
Card reader integrated | Yes |
Built-in HDD | No |
COMPATIBLE MEMORY CARDS | MicroSDXC |
Ethernet LAN (RJ-45) ports | 1 |
Angle of rotation | 355° |
Camera pan control | Yes |
Camera tilt control | Yes |
Pan range | 0 - 355° |
Camera shutter speed | 1/3 - 1/100000 s |
Tilt angle range | 0 - 75° |
Sensor type | CMOS |
Number of sensors | 1 |
Progressive Scan | Yes |
Optical sensor size | 25.4 / 3 mm (1 / 3") |
Supported graphics resolutions | 1280 x 720 (HD 720) |
Back Light Compensation (BLC) | Yes |
Noise reduction | Yes |
Privacy masking | Yes |
Noise reduction technology | 3D noise reduction |
Video streaming | Yes |
Bit rate | 32 Kbps - 8 Mbps |
Highlight Compensation (HLC) | Yes |
Image quality adjustment | Saturation |
Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
Total megapixels | 4 MP |
Region of Interest (ROI) encoding | Yes |
Video compression formats | H.265+ |
Frame rate | 30 fps |
Maximum Resolution | 2688 x 1520 pixels |
Night Vision | Yes |
LED type | IR |
Infra-red wavelength | 850 nm |
Night vision distance | 40 m |
Number of lenses | 1 |
Focal length range | 2.8 - 12 mm |
Maximum aperture number | 1.6 |
