| Product colour | Black |
| Power consumption (typical) | 15 W |
| Output current | 3.3 A |
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature | -10°C ~ +55°C |
| Weight | 1 kg |
| Height | 52 mm |
| Width | 385 mm |
| Depth | 315 mm |
| Mobile operating systems supported | iOS |
| Windows operating systems supported | Yes |
| Mac compatibility | Yes |
| Browser supported | IE, Firefox, Chrome, Edge, Safari |
| Mac operating systems supported | Yes |
| Supported resolutions | 4K (3840×2160) / 30 Hz, 2K (2560×1440) / 60 Hz, 1920×1080 / 60 Hz, 1600×1200 / 60 Hz, 1280×1024 / 60 Hz, 1280×720 / 60 Hz, 1024×768 / 60 Hz |
| Maximum Resolution | 3840 x 2160 pixels |
| Video input channels | 8 channels |
| Wi-Fi | No |
| Number of HDDs supported | 2 |
| HDD interface | Serial ATA |
| Total Storage Capacity | 32 TB |
| HDD Capacity | 16 TB |
| USB 2.0 ports quantity | 2 |
| Audio RCA outputs | 1 |
| Supported network protocols | HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, SNMP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPoE,DDNS, FTP |
| HDMI ports quantity | 1 |
| VGA (D-Sub) output ports | 1 |
| Power Over Ethernet (PoE) | No |
| Ethernet | One 10/100Mbps RJ45 port |
| Audio RCA inputs | 1 |
