Form factor | Dome |
Product colour | White |
Mounting Type | Ceiling/wall |
International Protection (IP) code | IP66 |
Protection features | Water resistant |
I code | IK10 |
Housing material | Metal |
Power source type | DC, PoE |
Power consumption (max) | 16 W |
Power consumption (Power over Ethernet (PoE)) | 18 W |
DC output voltage | 12 |
DC output current | 1.35 A |
Flash log | Yes |
Audit log | Yes |
Security algorithms | TLS |
Intelligent Video Surveillance (IVS) system features | Face detection |
Alert notification type | E-mail |
Video motion detection | Yes |
Heartbeat | Yes |
Digital watermark | Yes |
PASSWORD PROTECTION | Yes |
Automatic Network Replenishment (ANR) | Yes |
IP address filtering | Yes |
Alarm input channels | 1 |
HTTPS encryption | Yes |
Alarm output channels | 1 |
Password reset via email | Yes |
Pixel counter | Yes |
Digest authentication | Yes |
Storage temperature (T-T) | -30 - 60 °C |
Operating temperature (T-T) | -30 - 60 °C |
Operating relative humidity (H-H) | 0 - 95% |
Storage relative humidity (H-H) | 0 - 95% |
Reset button | Yes |
Behavior analysis | Line crossing detection, Region entrance detection, Region exiting detection |
Web browser | Yes |
Weight | 820 g |
Diameter | 15.5 cm |
Height | 140.4 mm |
Bluetooth | No |
Networking standards | IEEE 802.1x |
Number of users | 32 user(s) |
Live view | Yes |
Ethernet interface type | Fast Ethernet |
Ethernet LAN | Yes |
Wi-Fi | No |
Number of simultaneous live view channels | 6 channels |
User access level | Administrator, Operator, User |
Certification | CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014,
RCM: AS/NZS CISPR 32: 2015,
IC: ICES-003: Issue 7,
KC: KN32: 2015, KN35: 2015
CB: IEC 62368-1: 2014+A11,
CE-LVD: EN 62368-1: 2014/A11: 2017,
LOA: IEC/EN 60950-1
CE-RoHS: 2011/65/EU,
WEEE: 2012/19/EU,
Reach: Regulation (EC) No 1907/2006
IK10: IEC 62262:2002,IP66: IEC 60529-2013 |
Connectivity Technology | Wired |
Type | IP security camera |
Alarm input/output | Yes |
Placement supported | Indoor & outdoor |
Infrared (IR) cut-off filter | Yes |
Number of languages | 33 |
Dynamic range | 120 dB |
Languages support | Multi |
Wide Dynamic Range (WDR) | Yes |
Day/night mode | Yes |
PACKAGE WEIGHT | 1.2 kg |
Package width | 206 mm |
Package height | 230 mm |
Package depth | 206 mm |
Number of Cameras | 1 |
Audio output channels | 1.0 channels |
Built-in microphone | Yes |
Built-in speaker(s) | Yes |
Audio codecs | G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC |
Signal-to-Noise Ratio (SNR) | 52 dB |
Audio input channels | 1.0 channels |
Bit rate range | 16 - 320 Kbit/s |
Sample rates | 8 - 48 kHz |
COMPATIBLE MEMORY CARDS | MicroSDHC |
Card reader integrated | Yes |
Built-in HDD | No |
Ethernet LAN (RJ-45) ports | 1 |
Tilt angle range | 0 - 85° |
Camera shutter speed | 1/3 - 1/100000 s |
Angle of rotation | 350° |
Pan range | 0 - 355° |
Number of Privacy masking areas | 4 |
Lens viewing angle, vertical | 58.1 - 23.1° |
Lens viewing angle, diagonal | 137.4 - 47.3° |
Lens viewing angle, horizontal | 112.3 - 41.2° |
Number of sensors | 1 |
Optical sensor size | 25.4 / 1.8 mm (1 / 1.8") |
Sensor type | CMOS |
Progressive Scan | Yes |
Supported graphics resolutions | 1280 x 720 (HD 720) |
Maximum Resolution | 3840 x 2160 pixels |
Image quality adjustment | Saturation |
Gain control type | Auto |
Privacy masking | Yes |
Video streaming | Yes |
Frame rate | 30 fps |
Back Light Compensation (BLC) | Yes |
Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
Highlight Compensation (HLC) | Yes |
Bit rate | 32 Kbps - 16 Mbps |
Region of Interest (ROI) encoding | Yes |
Total megapixels | 8 MP |
Video compression formats | H.264+ |
Night Vision | Yes |
Infra-red wavelength | 850 nm |
Night vision distance | 40 m |
LED type | IR/White |
Identify distance (wide) | 9 m |
Identify distance (tele) | 22 m |
Recognize distance (tele) | 44 m |
Number of lenses | 1 |
Maximum aperture number | 1.2 |
Detect distance (wide) | 89 m |
Observe distance (wide) | 35 m |
Focal length range | 2.8 - 12 mm |
Recognize distance (wide) | 18 m |
Observe distance (tele) | 87 m |
Detect distance (tele) | 220 m |
Warnings | The product contains electronic components; do not dispose of with the normal household waste. |
