Housing material | Aluminium |
International Protection (IP) code | IP67 |
Form factor | Dome |
Protection features | Vandal proof |
I code | IK10 |
Mounting Type | Ceiling/wall |
Product colour | White |
DC output voltage | 12 |
Power consumption (max) | 7.8 W |
DC output current | 0.65 A |
Power consumption (Power over Ethernet (PoE)) | 9.5 W |
Power source type | DC, PoE |
Heartbeat | Yes |
PASSWORD PROTECTION | Yes |
Video motion detection | Yes |
HTTPS encryption | Yes |
Pixel counter | Yes |
Mirror | Yes |
Password reset via email | Yes |
Active tampering alarm | Yes |
Alarm output channels | 1 |
Alarm input channels | 1 |
IP address filtering | Yes |
Automatic Network Replenishment (ANR) | Yes |
Audit log | Yes |
Digest authentication | Yes |
Security algorithms | TLS |
Storage relative humidity (H-H) | 0 - 95% |
Operating relative humidity (H-H) | 0 - 95% |
Operating temperature (T-T) | -30 - 60 °C |
Storage temperature (T-T) | -30 - 60 °C |
Behavior analysis | Line crossing detection |
Web browser | Yes |
Reset button | Yes |
Diameter | 12.2 cm |
Height | 97.6 mm |
Weight | 600 g |
Live view | Yes |
Wi-Fi | No |
User access level | Administrator, Operator, User |
Ethernet interface type | Fast Ethernet |
Ethernet LAN | Yes |
Number of users | 32 user(s) |
Number of simultaneous live view channels | 6 channels |
Networking standards | IEEE 802.3af |
Bluetooth | No |
Certification | CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021,
RCM: AS/NZS CISPR 32: 2015,
IC: ICES-003: Issue 7,
KC: KN32: 2015, KN35: 2015
CB: IEC 62368-1: 2014+A11,
CE-LVD: EN 62368-1: 2014/A11: 2017,
BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005,
LOA: IEC/EN 60950-1
CE-RoHS: 2011/65/EU,
WEEE: 2012/19/EU,
Reach: Regulation (EC) No 1907/2006
IP67: IEC 60529-2013,IK10: IEC 62262:2002 |
Alarm input/output | Yes |
Type | IP security camera |
Number of languages | 33 |
Languages support | Multi |
Infrared (IR) cut-off filter | Yes |
Day/night mode | Yes |
Placement supported | Indoor & outdoor |
Dynamic range | 120 dB |
Wide Dynamic Range (WDR) | Yes |
Connectivity Technology | Wired |
Package height | 141 mm |
Package width | 150 mm |
PACKAGE WEIGHT | 840 g |
Package depth | 150 mm |
Number of Cameras | 1 |
Signal-to-Noise Ratio (SNR) | 52 dB |
Audio codecs | G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC |
Audio input channels | 1.0 channels |
Sample rates | 8 - 48 kHz |
Number of microphones | 2 |
Bit rate range | 8 - 320 Kbit/s |
Built-in microphone | Yes |
Audio output channels | 1.0 channels |
COMPATIBLE MEMORY CARDS | MicroSD (TransFlash) |
Built-in HDD | No |
Card reader integrated | Yes |
Maximum memory card size | 512 GB |
Ethernet LAN (RJ-45) ports | 1 |
Terminal block port | Yes |
Camera shutter speed | 1/3 - 1/100000 s |
Pan range | 0 - 355° |
Minimum illumination | 0 lx |
Angle of rotation | 355° |
Lens viewing angle, vertical | 44° |
Number of Privacy masking areas | 8 |
Lens viewing angle, horizontal | 88° |
Lens viewing angle, diagonal | 105° |
Tilt angle range | 0 - 75° |
Progressive Scan | Yes |
Number of sensors | 1 |
Optical sensor size | 25.4 / 2.8 mm (1 / 2.8") |
Sensor type | CMOS |
Video recording | Yes |
Supported graphics resolutions | 3200 x 1800 |
Back Light Compensation (BLC) | Yes |
Video compression formats | H.265 |
Video streaming | Yes |
Gain control type | Auto |
Region of Interest (ROI) encoding | Yes |
Total megapixels | 8 MP |
Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
Noise reduction | Yes |
Noise reduction technology | 3D noise reduction |
Highlight Compensation (HLC) | Yes |
Frame rate | 30 fps |
Bit rate | 32 Kbps - 16 Mbps |
Maximum Resolution | 3840 x 2160 pixels |
Night vision distance | 30 m |
Infra-red wavelength | 850 nm |
Night Vision | Yes |
LED type | IR/White |
Detect distance | 117 m |
Maximum aperture number | 1.6 |
Fixed focal length | 4 mm |
Identify distance | 11 m |
Recognize distance | 23 m |
Observe distance | 46 m |
Number of lenses | 1 |
Warnings | The product contains electronic components; do not dispose of with the normal household waste. |
