Housing material | Metal |
Mounting Type | Ceiling/wall |
Protection features | Dust resistant |
International Protection (IP) code | IP67 |
Product colour | White |
Form factor | Dome |
DC output current | 0.58 A |
Power consumption (Power over Ethernet (PoE)) | 9 W |
DC output voltage | 12 |
Power consumption (max) | 7 W |
Power source type | DC, PoE |
Privacy protection | Yes |
Heartbeat | Yes |
Active tampering alarm | Yes |
HTTPS encryption | Yes |
Intelligent Video Surveillance (IVS) system features | Face detection |
Human and vehicle targets classification | Yes |
Video motion detection | Yes |
Mirror | Yes |
PASSWORD PROTECTION | Yes |
Digest authentication | Yes |
IP address filtering | Yes |
Pixel counter | Yes |
Password reset via email | Yes |
Audit log | Yes |
Network access storage (NAS) | Yes |
Flash log | Yes |
Automatic Network Replenishment (ANR) | Yes |
Storage temperature (T-T) | -30 - 60 °C |
Operating relative humidity (H-H) | 0 - 95% |
Storage relative humidity (H-H) | 0 - 95% |
Operating temperature (T-T) | -30 - 60 °C |
Behavior analysis | Intrusion detection, Line crossing detection |
Reset button | Yes |
Web-based management | Yes |
Software reset | Yes |
Diameter | 12.7 cm |
Weight | 515 g |
Height | 96.3 mm |
Bluetooth | No |
Networking standards | IEEE 802.2x |
Ethernet interface type | Fast Ethernet |
Number of users | 32 user(s) |
Ethernet LAN | Yes |
Live view | Yes |
Wi-Fi | No |
Quality of Service (QoS) support | Yes |
Client interoperability | iVMS-4200, Hik-Connect, Hik-Central |
Number of simultaneous live view channels | 6 channels |
User access level | Administrator, Operator, User |
Dynamic range | 120 dB |
Languages support | Multi |
Day/night mode | Yes |
Connectivity Technology | Wired |
Infrared (IR) cut-off filter | Yes |
Number of languages | 33 |
Type | IP security camera |
Wide Dynamic Range (WDR) | Yes |
Placement supported | Outdoor |
Package width | 150 mm |
Package height | 141 mm |
PACKAGE WEIGHT | 755 g |
Package depth | 150 mm |
Number of Cameras | 1 |
Built-in microphone | Yes |
Built-in HDD | No |
Maximum memory card size | 512 GB |
COMPATIBLE MEMORY CARDS | MicroSD (TransFlash) |
Card reader integrated | Yes |
Ethernet LAN (RJ-45) ports | 1 |
Minimum illumination | 0 lx |
Angle of rotation | 360° |
Lens viewing angle, vertical | 57° |
Lens viewing angle, diagonal | 122° |
Pan range | 0 - 360° |
Lens viewing angle, horizontal | 104° |
Camera shutter speed | 1/3 - 1/100000 s |
Tilt angle range | 0 - 75° |
Number of Privacy masking areas | 8 |
Optical sensor size | 25.4 / 2.9 mm (1 / 2.9") |
Number of sensors | 1 |
Sensor type | CMOS |
Progressive Scan | Yes |
Frame rate | 30 fps |
Video streaming | Yes |
Supported video modes | 720p |
Image quality adjustment | Sharpness |
Video compression formats | M-JPEG |
Highlight Compensation (HLC) | Yes |
Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
Supported graphics resolutions | 1920 x 1080 (HD 1080) |
Privacy masking | Yes |
Region of Interest (ROI) encoding | Yes |
Maximum Resolution | 2688 x 1520 pixels |
Bit rate | 32 Kbps - 8 Mbps |
Back Light Compensation (BLC) | Yes |
Noise reduction | Yes |
Total megapixels | 4 MP |
Noise reduction technology | 3D noise reduction |
LED type | IR |
Night Vision | Yes |
Infra-red wavelength | 850 nm |
Night vision distance | 30 m |
Recognize distance | 12 m |
Fixed focal length | 2.8 mm |
Maximum aperture number | 1.6 |
Observe distance | 25 m |
Identify distance | 6 m |
Fixed focus | Yes |
Detect distance | 63 m |
Number of lenses | 1 |
Warnings | Avoid direct contact with water to prevent electrical damage. |
Sustainability compliance | Yes |
Compliance certificates | Low Voltage Directive (LVD) |
