Lens mount interface | M12 |
Housing material | Metal |
Product colour | Black |
Protection features | Water resistant |
International Protection (IP) code | IP67 |
Mounting Type | Ceiling/wall |
Form factor | Turret |
Power source type | DC, PoE |
Power consumption (max) | 7 W |
DC output current | 0.58 A |
Power consumption (Power over Ethernet (PoE)) | 8.5 W |
DC output voltage | 12 |
Security algorithms | EAP-MD5 |
Heartbeat | Yes |
Digital watermark | Yes |
Intelligent Video Surveillance (IVS) system features | Face detection |
Pixel counter | Yes |
IP address filtering | Yes |
HTTPS encryption | Yes |
Privacy protection | Yes |
Video motion detection | Yes |
Human and vehicle targets classification | Yes |
Digest authentication | Yes |
PASSWORD PROTECTION | Yes |
Mirror | Yes |
Password reset via email | Yes |
Active tampering alarm | Yes |
Network access storage (NAS) | Yes |
Audit log | Yes |
Automatic Network Replenishment (ANR) | Yes |
Storage relative humidity (H-H) | 0 - 95% |
Storage temperature (T-T) | -30 - 60 °C |
Operating relative humidity (H-H) | 0 - 95% |
Operating temperature (T-T) | -30 - 60 °C |
Behavior analysis | Intrusion detection, Line crossing detection |
Reset button | Yes |
Web-based management | Yes |
Weight | 775 g |
Diameter | 13.8 cm |
Height | 115.4 mm |
Ethernet interface type | Fast Ethernet |
Number of simultaneous live view channels | 6 channels |
Bluetooth | No |
Wi-Fi | No |
User access level | Administrator, Operator, User |
Quality of Service (QoS) support | Yes |
Ethernet LAN | Yes |
Number of users | 32 user(s) |
Live view | Yes |
Networking standards | IEEE 802.1x |
Client interoperability | iVMS-4200, Hik-Connect, Hik-Central |
Connectivity Technology | Wired |
Dynamic range | 120 dB |
Wide Dynamic Range (WDR) | Yes |
Infrared (IR) cut-off filter | Yes |
Placement supported | Outdoor |
Languages support | Multi |
Type | IP security camera |
Day/night mode | Yes |
Number of languages | 33 |
Package depth | 170 mm |
Package height | 160 mm |
PACKAGE WEIGHT | 1.23 kg |
Package width | 170 mm |
Number of Cameras | 1 |
Audio formats supported | G.726 |
Signal-to-Noise Ratio (SNR) | 52 dB |
Built-in microphone | Yes |
Bit rate range | 8 - 320 Kbit/s |
Sample rates | 8 - 48 kHz |
COMPATIBLE MEMORY CARDS | MicroSD (TransFlash) |
Built-in HDD | No |
Card reader integrated | Yes |
Maximum memory card size | 512 GB |
Ethernet LAN (RJ-45) ports | 1 |
Lens viewing angle, vertical | 47.2° |
Lens viewing angle, diagonal | 114.2° |
Camera shutter speed | 1/3 - 1/100000 s |
Angle of rotation | 360° |
Tilt angle range | 0 - 90° |
Lens viewing angle, horizontal | 93.3° |
Minimum illumination | 0 lx |
Pan range | 0 - 360° |
Number of Privacy masking areas | 4 |
Browser supported | IE 10, IE 11, Chrome 57.0+, Firefox 52.0+ |
Progressive Scan | Yes |
Optical sensor size | 25.4 / 1.8 mm (1 / 1.8") |
Sensor type | CMOS |
Number of sensors | 1 |
Supported graphics resolutions | 1280 x 720 (HD 720) |
Image quality adjustment | Sharpness |
Video compression formats | H.264 |
Back Light Compensation (BLC) | Yes |
Frame rate | 30 fps |
Bit rate | 32 Kbps - 16 Mbps |
Noise reduction | Yes |
Region of Interest (ROI) encoding | Yes |
Video streaming | Yes |
Smart IR | Yes |
Total megapixels | 8 MP |
Privacy masking | Yes |
Maximum Resolution | 3840 x 2160 pixels |
Noise reduction technology | 3D noise reduction |
Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
Highlight Compensation (HLC) | Yes |
Night vision distance | 30 m |
Infra-red wavelength | 850 nm |
LED type | IR |
Night Vision | Yes |
Observe distance | 43 m |
Identify distance | 10 m |
Detect distance | 109 m |
Maximum aperture number | 1 |
Recognize distance | 21 m |
Number of lenses | 1 |
Fixed focal length | 4 mm |
Compliance certificates | RoHS |
