Mounting Type | Ceiling/wall |
Protection features | Vandal proof |
I code | IK10 |
Form factor | Bullet |
Housing material | Metal |
Product colour | White |
International Protection (IP) code | IP67 |
DC output current | 0.66 A |
DC output voltage | 12 |
Power consumption (Power over Ethernet (PoE)) | 9.5 W |
Power consumption (max) | 8 W |
Power source type | DC, PoE |
IP address filtering | Yes |
HTTPS encryption | Yes |
Video motion detection | Yes |
PASSWORD PROTECTION | Yes |
Password reset via email | Yes |
Digest authentication | Yes |
Pixel counter | Yes |
Heartbeat | Yes |
Flash log | Yes |
Active tampering alarm | Yes |
Human and vehicle targets classification | Yes |
Digital watermark | Yes |
Mirror | Yes |
Privacy protection | Yes |
Audit log | Yes |
Network access storage (NAS) | Yes |
Automatic Network Replenishment (ANR) | Yes |
Security algorithms | TLS |
Storage relative humidity (H-H) | 0 - 95% |
Operating temperature (T-T) | -30 - 60 °C |
Storage temperature (T-T) | -30 - 60 °C |
Operating relative humidity (H-H) | 0 - 95% |
Web browser | Yes |
Behavior analysis | Intrusion detection, Line crossing detection |
Reset button | Yes |
Web-based management | Yes |
Height | 93.1 mm |
Weight | 1.16 kg |
Width | 88.7 mm |
Length | 286.7 mm |
Number of users | 32 user(s) |
Number of simultaneous live view channels | 6 channels |
User access level | Administrator, Operator, User |
Live view | Yes |
Networking standards | IEEE 802.3at |
Wi-Fi | No |
Bluetooth | No |
Quality of Service (QoS) support | Yes |
Ethernet interface type | Fast Ethernet |
Ethernet LAN | Yes |
Day/night mode | Yes |
Placement supported | Outdoor |
Number of languages | 33 |
Languages support | Multi |
Infrared (IR) cut-off filter | Yes |
Dynamic range | 120 dB |
Type | IP security camera |
Connectivity Technology | Wired |
Wide Dynamic Range (WDR) | Yes |
PACKAGE WEIGHT | 1.66 kg |
Package width | 386 mm |
Package height | 155 mm |
Package depth | 156 mm |
Number of Cameras | 1 |
Signal-to-Noise Ratio (SNR) | 52 dB |
Maximum memory card size | 512 GB |
Built-in HDD | No |
COMPATIBLE MEMORY CARDS | MicroSDHC |
Card reader integrated | Yes |
Ethernet LAN (RJ-45) ports | 1 |
Pan range | 0 - 360° |
Camera shutter speed | 1/3 - 1/100000 s |
Lens viewing angle, horizontal | 88° |
Lens viewing angle, vertical | 44° |
Lens viewing angle, diagonal | 105° |
Number of Privacy masking areas | 8 |
Tilt angle range | 0 - 90° |
Minimum illumination | 0 lx |
Angle of rotation | 360° |
Optical sensor size | 25.4 / 2.8 mm (1 / 2.8") |
Sensor type | CMOS |
Progressive Scan | Yes |
Number of sensors | 1 |
Total megapixels | 4 MP |
Video formats supported | H.264+ |
Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
Privacy masking | Yes |
Noise reduction technology | 3D noise reduction |
Gain control type | Auto |
Video compression formats | H.264 |
Video streaming | Yes |
Region of Interest (ROI) encoding | Yes |
Noise reduction | Yes |
Frame rate | 30 fps |
Video recording | Yes |
Image quality adjustment | Sharpness |
Supported graphics resolutions | 2688 x 1520 |
Maximum Resolution | 3840 x 2160 pixels |
Bit rate | 32 Kbps - 16 Mbps |
Back Light Compensation (BLC) | Yes |
Highlight Compensation (HLC) | Yes |
Night Vision | Yes |
Infra-red wavelength | 850 nm |
LED type | IR/White |
Night vision distance | 60 m |
Observe distance | 46 m |
Recognize distance | 23 m |
Fixed focal length | 4 mm |
Detect distance | 117 m |
Maximum aperture number | 1.6 |
Identify distance | 11 m |
Number of lenses | 1 |
Warnings | Avoid direct contact with water to prevent electrical damage. |
Compliance certificates | WEEE |
