Housing material | Polycarbonate (PC) |
Mounting Type | Ceiling |
Product colour | White |
Form factor | Turret |
International Protection (IP) code | IP66 |
DC output voltage | 12 |
Power source type | DC, PoE |
Intelligent Video Surveillance (IVS) system features | Line crossing detection |
HTTPS encryption | Yes |
IP address filtering | Yes |
Video motion detection | Yes |
Digital watermark | Yes |
PASSWORD PROTECTION | Yes |
Mirror | Yes |
Active tampering alarm | Yes |
Security algorithms | 802.1x RADIUS |
Human and vehicle targets classification | Yes |
Operating relative humidity (H-H) | 0 - 95% |
Operating temperature (T-T) | -30 - 50 °C |
Reset button | Yes |
Height | 311.5 mm |
Weight | 1.37 kg |
Depth | 223.5 mm |
Width | 156 mm |
Number of users | 32 user(s) |
Number of simultaneous live view channels | 20 channels |
Live view | Yes |
User access level | Administrator, Operator, User |
Bluetooth | No |
Wi-Fi | No |
Ethernet LAN | Yes |
Alarm input/output | Yes |
Placement supported | Indoor & outdoor |
Wide Dynamic Range (WDR) | Yes |
PTZ control | Yes |
Day/night mode | Yes |
Preset freezing function | Yes |
PTZ status display | Yes |
Dynamic range | 120 dB |
Connectivity Technology | Wired |
Type | IP security camera |
Number of Cameras | 1 |
Audio formats supported | G.711 |
Signal-to-Noise Ratio (SNR) | 52 dB |
Bit rate range | 32 - 160 Kbit/s |
Sample rates | 8 - 16 kHz |
Built-in HDD | No |
Maximum memory card size | 512 GB |
COMPATIBLE MEMORY CARDS | MicroSD (TransFlash) |
Card reader integrated | Yes |
Ethernet LAN (RJ-45) ports | 1 |
Pan speed | 30 °/sec |
Preset programs quantity | 300 |
Pan range | 0 - 350° |
Minimum illumination | 0 lx |
Camera shutter speed | 1 - 1/30000 s |
Tilt speed | 30 °/sec |
Tilt preset speed | 30 °/sec |
Pan preset speed | 30 °/sec |
Number of Privacy masking areas | 24 |
Lens viewing angle, vertical | 62.4° |
Tilt angle range (panoramic camera) | -5 - 90° |
Camera pan control | Yes |
Camera tilt control | Yes |
Lens viewing angle, diagonal | 130.7° |
Lens viewing angle, horizontal | 114.9° |
Tilt angle range | 7 - 17° |
Optical sensor size | 25.4 / 2.8 mm (1 / 2.8") |
Progressive Scan | Yes |
Sensor type | CMOS |
Back Light Compensation (BLC) | Yes |
Region of Interest (ROI) encoding | Yes |
Noise reduction technology | 3D noise reduction |
Highlight Compensation (HLC) | Yes |
Video compression formats | H.265 |
Bit rate | 32 Kbps - 16384 Kbps |
Total megapixels | 4 MP |
Noise reduction | Yes |
3D positioning | Yes |
Image quality adjustment | Sharpness |
Supported graphics resolutions | 2560 x 1440 |
Maximum Resolution | 2560 x 1440 pixels |
LED type | IR/White |
Night vision distance | 40 m |
Night Vision | Yes |
Fixed focal length | 2.8 mm |
Zoom capability | Yes |
Focus | Motorized/Manual |
Optical zoom | 4x |
Digital zoom | 16x |
Observe distance | 62.1 m |
Identify distance | 15.7 m |
Detect distance | 156.5 m |
Maximum aperture number | 1.6 |
Recognize distance | 31.3 m |
Auto focus | Yes |
Zoom speed | 3.3 s |
Warnings | Avoid direct contact with water to prevent electrical damage. |
Optical sensor size (panoramic camera) | 25.4 / 2.8 mm (1 / 2.8") |
Viewing angle, vertical (panoramic camera) | 52° |
Maximum aperture number (panoramic camera) | 2.9 |
Focal length range (panoramic camera) | 2.8 - 14 mm |
Minimum illumination (panoramic camera) | 0 lx |
Minimum aperture number (panoramic camera) | 1.5 |
Viewing angle, horizontal (panoramic camera) | 98° |
