Sustainability certificates | REACH |
Housing material | Aluminium |
Product colour | White |
International Protection (IP) code | IP67 |
I code | IK10 |
Form factor | Turret |
Mounting Type | Ceiling/wall |
DC output voltage | 12 |
Power consumption (Power over Ethernet (PoE)) | 12.5 W |
Power consumption (max) | 11 W |
Power source type | DC, PoE |
Intelligent Video Surveillance (IVS) system features | Face detection |
Heartbeat | Yes |
Video motion detection | Yes |
HTTPS encryption | Yes |
Mirror | Yes |
PASSWORD PROTECTION | Yes |
Anti-flicker | Yes |
IP address filtering | Yes |
Storage relative humidity (H-H) | 0 - 95% |
Operating relative humidity (H-H) | 0 - 95% |
Storage temperature (T-T) | -30 - 60 °C |
Operating temperature (T-T) | -30 - 60 °C |
Reset button | Yes |
Behavior analysis | Intrusion detection, Line crossing detection |
Web browser | Yes |
Web-based management | Yes |
Diameter | 13.8 cm |
Height | 126 mm |
Weight | 830 g |
Package width | 216 mm |
Package depth | 121 mm |
PACKAGE WEIGHT | 1.11 kg |
Package height | 118 mm |
Number of users | 32 user(s) |
Wi-Fi | No |
Ethernet interface type | Fast Ethernet |
Ethernet LAN | Yes |
Networking standards | IEEE 802.1x |
Quality of Service (QoS) support | Yes |
Bluetooth | No |
Wide Dynamic Range (WDR) | Yes |
Placement supported | Outdoor |
Number of languages | 33 |
Day/night mode | Yes |
Infrared (IR) cut-off filter | Yes |
Type | IP security camera |
Connectivity Technology | Wired |
Number of Cameras | 1 |
Voice Codecs | G.726 |
Audio formats supported | MP3 |
Sample Rate | 48 kHz |
COMPATIBLE MEMORY CARDS | MicroSD (TransFlash) |
Card reader integrated | Yes |
Built-in HDD | No |
Maximum memory card size | 256 GB |
Ethernet LAN (RJ-45) ports | 1 |
Pan range | 0 - 360° |
Camera pan control | Yes |
Camera tilt control | Yes |
Angle of rotation | 360° |
Tilt angle range | 0 - 90° |
Camera shutter speed | 1/3 - 1/100000 s |
Harmonized System (HS) code | 85258900 |
Sensor type | CMOS |
Number of sensors | 1 |
Optical sensor size | 25.4 / 3 mm (1 / 3") |
Progressive Scan | Yes |
Video compression formats | H.265+ |
Total megapixels | 4 MP |
Bit rate | 32 Kbps - 8 Mbps |
Video streaming | Yes |
Highlight Compensation (HLC) | Yes |
Maximum Resolution | 2688 x 1520 pixels |
Supported graphics resolutions | 1280 x 720 (HD 720) |
Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
Back Light Compensation (BLC) | Yes |
Frame rate | 30 fps |
Image quality adjustment | Contrast |
Privacy masking | Yes |
Region of Interest (ROI) encoding | Yes |
Noise reduction technology | 3D noise reduction |
Noise reduction | Yes |
LED type | IR |
Night vision distance | 40 m |
Infra-red wavelength | 850 nm |
Night Vision | Yes |
Maximum aperture number | 1.6 |
Number of lenses | 1 |
