Mounting Type | Ceiling/wall |
Housing material | Metal |
I code | IK08 |
Protection features | Dust resistant |
Form factor | Dome |
Product colour | White |
International Protection (IP) code | IP67 |
DC output current | 0.4 A |
Power consumption (Power over Ethernet (PoE)) | 6.5 W |
DC output voltage | 12 |
Power source type | DC, PoE |
Power consumption (max) | 5 W |
Heartbeat | Yes |
Password reset via email | Yes |
HTTPS encryption | Yes |
Privacy protection | Yes |
Active tampering alarm | Yes |
Video motion detection | Yes |
Mirror | Yes |
PASSWORD PROTECTION | Yes |
Pixel counter | Yes |
Human and vehicle targets classification | Yes |
Audit log | Yes |
Digest authentication | Yes |
Security algorithms | EAP-MD5 |
Operating temperature (T-T) | -30 - 60 °C |
Storage temperature (T-T) | -30 - 60 °C |
Storage relative humidity (H-H) | 0 - 95% |
Operating relative humidity (H-H) | 0 - 95% |
Web browser | Yes |
Behavior analysis | Intrusion detection, Line crossing detection |
Web-based management | Yes |
Height | 84.7 mm |
Weight | 520 g |
Length | 170.8 mm |
Number of users | 32 user(s) |
Supported network protocols | TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, RTCP, NTP, IGMP, IPv4, IPv6, UDP, QoS, FTP, SMTP, HTTPS, DDNS, UPnP, 802.1X |
User access level | Administrator, Operator, User |
Number of simultaneous live view channels | 6 channels |
Live view | Yes |
Bluetooth | No |
Wi-Fi | No |
Networking standards | IEEE 802.1x |
Ethernet LAN | Yes |
Quality of Service (QoS) support | Yes |
Ethernet interface type | Fast Ethernet |
Infrared (IR) cut-off filter | Yes |
Wide Dynamic Range (WDR) | Yes |
Languages support | Multi |
Day/night mode | Yes |
Dynamic range | 120 dB |
Placement supported | Outdoor |
Type | IP security camera |
Connectivity Technology | Wired |
Package depth | 134 mm |
Package width | 134 mm |
Package height | 108 mm |
PACKAGE WEIGHT | 720 g |
Number of Cameras | 1 |
Signal-to-Noise Ratio (SNR) | 52 dB |
Built-in HDD | No |
Ethernet LAN (RJ-45) ports | 1 |
Pan range | 0 - 360° |
Angle of rotation | 360° |
Minimum illumination | 0 lx |
Camera shutter speed | 1/3 - 1/100000 s |
Lens viewing angle, diagonal | 116.1° |
Lens viewing angle, horizontal | 99.5° |
Lens viewing angle, vertical | 55.5° |
Number of Privacy masking areas | 4 |
Tilt angle range | 0 - 90° |
Optical sensor size | 25.4 / 2.9 mm (1 / 2.9") |
Number of sensors | 1 |
Sensor type | CMOS |
Progressive Scan | Yes |
Video recording | Yes |
Video formats supported | M-JPEG |
Noise reduction | Yes |
Image quality adjustment | Sharpness |
Frame rate | 30 fps |
Video compression formats | H.265+ |
Privacy masking | Yes |
Back Light Compensation (BLC) | Yes |
Video streaming | Yes |
Noise reduction technology | 3D noise reduction |
Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
Region of Interest (ROI) encoding | Yes |
Total megapixels | 4 MP |
Gain control type | Auto |
Highlight Compensation (HLC) | Yes |
Supported graphics resolutions | 640 x 360 |
Bit rate | 32 Kbps - 8 Mbps |
Maximum Resolution | 2560 x 1440 pixels |
LED type | IR |
Infra-red wavelength | 850 nm |
Night Vision | Yes |
Night vision distance | 40 m |
Detect distance | 59 m |
Identify distance | 5 m |
Recognize distance | 11 m |
Fixed focal length | 2.8 mm |
Observe distance | 23 m |
Number of lenses | 1 |
Maximum aperture number | 2 |
Warnings | The product contains electronic components; do not dispose of with the normal household waste. |
Compliance certificates | Federal Communications Commission (FCC) |
