Lens mount interface | M12 |
Form factor | Turret |
Housing material | Metal |
Protection features | Water resistant |
Mounting Type | Ceiling/Wall/Pole |
International Protection (IP) code | IP67 |
Product colour | White |
Power source type | DC, PoE |
Power consumption (Power over Ethernet (PoE)) | 9.5 W |
Power consumption (max) | 8 W |
DC output current | 0.66 A |
DC output voltage | 12 |
Audit log | Yes |
Digest authentication | Yes |
Password reset via email | Yes |
PASSWORD PROTECTION | Yes |
Mirror | Yes |
Video motion detection | Yes |
Active tampering alarm | Yes |
Digital watermark | Yes |
Heartbeat | Yes |
Storage temperature (T-T) | -30 - 60 °C |
Operating temperature (T-T) | -30 - 60 °C |
Operating relative humidity (H-H) | 0 - 95% |
Storage relative humidity (H-H) | 0 - 95% |
Reset button | Yes |
Height | 102.7 mm |
Weight | 385 g |
Diameter | 11 cm |
User access level | Administrator, Operator, User |
Number of simultaneous live view channels | 6 channels |
Ethernet LAN | Yes |
Ethernet interface type | Fast Ethernet |
Wi-Fi | No |
Networking standards | IEEE 802.3af |
Supported network protocols | TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP, UPnP |
Number of users | 32 user(s) |
Bluetooth | No |
Dynamic range | 120 dB |
Number of languages | 2 |
Connectivity Technology | Wired |
Infrared (IR) cut-off filter | Yes |
Built-in light | Yes |
Languages support | English |
Placement supported | Indoor & outdoor |
Day/night mode | Yes |
Type | IP security camera |
Wide Dynamic Range (WDR) | Yes |
PACKAGE WEIGHT | 586 g |
Package height | 141 mm |
Package width | 150 mm |
Package depth | 150 mm |
Number of Cameras | 1 |
Bit rate range | 16 - 160 Kbit/s |
Sample rates | 8 - 16 kHz |
Audio formats supported | PCM |
Signal-to-Noise Ratio (SNR) | 52 dB |
Built-in microphone | Yes |
Audio system | 2-way |
Built-in speaker(s) | Yes |
COMPATIBLE MEMORY CARDS | MicroSD (TransFlash) |
Built-in HDD | No |
Card reader integrated | No |
Maximum memory card size | 512 GB |
Ethernet LAN (RJ-45) ports | 1 |
Number of Privacy masking areas | 4 |
Lens viewing angle, diagonal | 134° |
Lens viewing angle, vertical | 62° |
Lens viewing angle, horizontal | 113° |
Angle of rotation | 360° |
Tilt angle range | 0 - 75° |
Pan range | 0 - 360° |
Camera shutter speed | 1/3 - 1/100000 s |
Minimum illumination | 0 lx |
Optical sensor size | 25.4 / 2.7 mm (1 / 2.7") |
Sensor type | CMOS |
Progressive Scan | Yes |
Supported graphics resolutions | 640 x 360 |
Image quality adjustment | Brightness |
Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
Noise reduction | Yes |
Total megapixels | 8 MP |
Video compression formats | H.265+ |
Region of Interest (ROI) encoding | Yes |
Back Light Compensation (BLC) | Yes |
Highlight Compensation (HLC) | Yes |
Noise reduction technology | 3D noise reduction |
Bit rate | 32 Kbps - 16 Mbps |
Maximum Resolution | 3840 x 2160 pixels |
Infra-red wavelength | 850 nm |
LED type | IR |
Night Vision | Yes |
Night vision distance | 30 m |
Identify distance | 7 m |
Detect distance | 79 m |
Recognize distance | 15 m |
Number of lenses | 1 |
Maximum aperture number | 2 |
Fixed focal length | 2.8 mm |
Observe distance | 31 m |
Compliance certificates | CB |
