Lens mount interface | M12 |
Mounting Type | Ceiling/wall |
Housing material | Metal |
International Protection (IP) code | IP67 |
Form factor | Bullet |
Product colour | White |
DC output voltage | 12 |
Power source type | DC, PoE |
Mirror | Yes |
Intelligent Video Surveillance (IVS) system features | Human detection |
Digital watermark | Yes |
Video motion detection | Yes |
Active tampering alarm | Yes |
PASSWORD PROTECTION | Yes |
Password reset via email | Yes |
Heartbeat | Yes |
Digest authentication | Yes |
Operating temperature (T-T) | -30 - 60 °C |
Storage relative humidity (H-H) | 0 - 95% |
Operating relative humidity (H-H) | 0 - 95% |
Storage temperature (T-T) | -30 - 60 °C |
Height | 69.1 mm |
Depth | 170.8 mm |
Width | 66 mm |
Weight | 265 g |
Ethernet LAN | Yes |
Wi-Fi | No |
Live view | Yes |
Number of users | 32 user(s) |
Supported network protocols | TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP |
User access level | Administrator, Operator, User |
Number of simultaneous live view channels | 6 channels |
Networking standards | IEEE 802.3af |
Bluetooth | No |
Languages support | English |
Infrared (IR) cut-off filter | Yes |
Alarm input/output | Yes |
Type | IP security camera |
Placement supported | Indoor & outdoor |
Number of languages | 2 |
Day/night mode | Yes |
Connectivity Technology | Wired |
Package depth | 216 mm |
Package width | 121 mm |
Package height | 118 mm |
PACKAGE WEIGHT | 495 g |
Number of Cameras | 1 |
Voice Codecs | G.726 |
Signal-to-Noise Ratio (SNR) | 52 dB |
Built-in microphone | Yes |
Card reader integrated | No |
Built-in HDD | No |
Ethernet LAN (RJ-45) ports | 1 |
Angle of rotation | 360° |
Camera shutter speed | 1/3 - 1/100000 s |
Pan range | 0 - 360° |
Minimum illumination | 0 lx |
Number of Privacy masking areas | 4 |
Lens viewing angle, vertical | 56° |
Lens viewing angle, diagonal | 121° |
Lens viewing angle, horizontal | 103° |
Tilt angle range | 0 - 90° |
Progressive Scan | Yes |
Sensor type | CMOS |
Number of sensors | 1 |
Optical sensor size | 25.4 / 2.9 mm (1 / 2.9") |
Back Light Compensation (BLC) | Yes |
Supported graphics resolutions | 1280 x 720 (HD 720) |
Frame rate | 30 fps |
Highlight Compensation (HLC) | Yes |
Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
Video compression formats | H.265 |
Image quality adjustment | Saturation |
Total megapixels | 2 MP |
Region of Interest (ROI) encoding | Yes |
Digital Wide Dynamic Range (DWDR) | Yes |
Noise reduction | Yes |
Privacy masking | Yes |
Noise reduction technology | 3D noise reduction |
Bit rate | 32 Kbps - 8 Mbps |
Maximum Resolution | 1920 x 1080 pixels |
Night vision distance | 30 m |
LED type | IR |
Night Vision | Yes |
Infra-red wavelength | 850 nm |
Fixed focal length | 2.8 mm |
Identify distance | 4 m |
Maximum aperture number | 1.6 |
Number of lenses | 1 |
Detect distance | 45 m |
Recognize distance | 9 m |
Observe distance | 18 m |
Sustainability compliance | Yes |
Compliance certificates | REACH |
