| Housing material | Metal, Plastic |
| Mounting Type | Ceiling |
| Product colour | White |
| International Protection (IP) code | IP67 |
| Form factor | Tube/dome |
| Degree of protection IK | IK10 |
| DC output voltage | 12 |
| Power consumption (max) | 4 W |
| Power source type | DC, PoE |
| Power consumption (Power over Ethernet (PoE)) | 6.5 W |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage temperature (T-T) | -40 - 60 °C |
| Operating temperature (T-T) | -30 - 60 °C |
| Web-based management | Yes |
| Web browser | Yes |
| Height | 75.9 mm |
| Depth | 249.2 mm |
| Weight | 820 g |
| Width | 79 mm |
| Ethernet interface type | Fast Ethernet |
| Networking standards | IEEE 802.3af |
| Bluetooth | No |
| Number of users | 20 user(s) |
| Wi-Fi | No |
| Quality of Service (QoS) support | Yes |
| Mobile operating systems supported | iOS |
| Certification | LVD: EN62368-1; EMC: Electromagnetic Compatibility Directive 2014/30/EU; FCC: 47 CFR FCC Part 15, Subpart B; UL/CUL: UL62368-1 CAN/CSA C22.2 No. 62368-1-14 2022-04-29 |
| Wide Dynamic Range (WDR) | 120 dB |
| Signal-to-Noise Ratio (SNR) | 56 dB |
| Placement supported | External / Internal |
| Connectivity Technology | Wired |
| Type | IP security camera |
| Number of Cameras | 1 |
| Audio formats supported | G.711a |
| Built-in microphone | Yes |
| INTERNAL MEMORY | 512 MB |
| ROM capacity | 128 MB |
| Built-in HDD | No |
| White balance | Auto |
| Minimum illumination | 0.001 lx |
| Pan range | 0 - 360° |
| Camera shutter speed | 1/3 - 1/100000 s |
| Adjustment shutter speed | Auto/Manual |
| Tilt angle range | 0 - 90° |
| Lens viewing angle, horizontal | 180° |
| Lens viewing angle, diagonal | 180° |
| Lens viewing angle, vertical | 78° |
| Optical sensor size | 25.4 / 2.7 mm (1 / 2.7") |
| Sensor type | CMOS |
| Progressive Scan | Yes |
| Number of sensors | 1 |
| Frame rate | 30 fps |
| Back Light Compensation (BLC) | Yes |
| Highlight Compensation (HLC) | Yes |
| Bit rate | 3 kbps–8192 kbps, H.265: 3 kbps–8192 kbps |
| Total megapixels | 4 MP |
| Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Gain control type | Auto/Manual |
| Region of Interest (ROI) encoding | Yes |
| Video compression formats | H.264B |
| Video streaming | Yes |
| Maximum Resolution | 2880 x 1620 pixels |
| Noise reduction technology | 3D noise reduction |
| Noise reduction | Yes |
| Supported graphics resolutions | 2560 x 1440 |
| Mirror function | Yes |
| LED type | IR |
| Number of illumination LEDs | 2 |
| Night vision distance | 20 m |
| Night Vision | Yes |
| Closest focusing distance | 0.6 m |
| Maximum aperture number | 2 |
| Focal length range | 2.1 - 2.31 mm |
| Number of lenses | 1 |
| Lens type | Varifocal |
