Mounting Type | Ceiling |
Housing material | Metal, Plastic |
International Protection (IP) code | IP67 |
Product colour | White |
Degree of protection IK | IK10 |
Form factor | Tube/dome |
DC output voltage | 12 |
Power consumption (Power over Ethernet (PoE)) | 6.5 W |
Power consumption (max) | 5.3 W |
Power source type | DC, PoE |
Storage temperature (T-T) | -40 - 60 °C |
Operating temperature (T-T) | -40 - 60 °C |
Operating relative humidity (H-H) | 0 - 95% |
Web browser | Yes |
Web-based management | Yes |
Height | 66.4 mm |
Depth | 192.7 mm |
Width | 70.5 mm |
Weight | 590 g |
Wi-Fi | No |
Number of users | 20 user(s) |
Ethernet interface type | Fast Ethernet |
Bluetooth | No |
Networking standards | IEEE 802.3af |
Quality of Service (QoS) support | Yes |
Mobile operating systems supported | Android |
Certification | LVD: EN62368-1; EMC: Electromagnetic Compatibility Directive 2014/30/EU; FCC: 47 CFR FCC Part 15, Subpart B; UL/CUL: UL62368-1 CAN/CSA C22.2 No. 62368-1-14 2022-12-08 |
Wide Dynamic Range (WDR) | 120 dB |
Signal-to-Noise Ratio (SNR) | 56 dB |
Placement supported | External / Internal |
Type | IP security camera |
Connectivity Technology | Wired |
Number of Cameras | 1 |
Audio formats supported | G.711a |
Built-in microphone | Yes |
INTERNAL MEMORY | 512 MB |
ROM capacity | 128 MB |
Built-in HDD | No |
Minimum illumination | 0.005 lx |
Adjustment shutter speed | Auto/Manual |
Camera shutter speed | 1/3 - 1/100000 s |
White balance | Outdoor |
Pan range | 0 - 360° |
Lens viewing angle, vertical | 58° |
Tilt angle range | 0 - 90° |
Lens viewing angle, diagonal | 132° |
Progressive Scan | Yes |
Sensor type | CMOS |
Optical sensor size | 25.4 / 2.7 mm (1 / 2.7") |
Number of sensors | 1 |
Highlight Compensation (HLC) | Yes |
Video compression formats | H.265 |
Frame rate | 30 fps |
Noise reduction | Yes |
Back Light Compensation (BLC) | Yes |
Bit rate | 3 kbps–8192 kbps, H.265: 3 kbps–8192 kbps |
Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
Noise reduction technology | 3D noise reduction |
Total megapixels | 5 MP |
Gain control type | Auto/Manual |
Video streaming | Yes |
Region of Interest (ROI) encoding | Yes |
Supported graphics resolutions | 352 x 240 |
Maximum Resolution | 2960 x 1668 px |
Mirror function | Yes |
Night Vision | Yes |
Number of illumination LEDs | 1 |
Night vision distance | 50 m |
LED type | IR |
Lens type | Fixed focal length lens |
Number of lenses | 1 |
Maximum aperture number | 1.4 |
Focal length range | 2.8 mm |
Closest focusing distance | 1.1 m |
