Product colour | White |
Housing material | Metal |
Form factor | Bullet |
Mounting Type | Ceiling/wall |
International Protection (IP) code | IP67 |
Power source type | DC, PoE |
DC output voltage | 12 |
Power consumption (max) | 7.6 W |
Power consumption (typical) | 4.5 W |
Power consumption (Power over Ethernet (PoE)) | 9.1 W |
Number of Privacy masking areas (panoramic camera) | 8 |
Voice commands | Yes |
LED indicators | Alarm |
Intelligent Video Surveillance (IVS) system features | Intrusion |
Light effects | Yes |
Sound Effects | Yes |
Alarm clock | Yes |
Mirror | Yes |
Video motion detection | Yes |
IP address filtering | Yes |
Storage relative humidity (H-H) | 0 - 95% |
Storage temperature (T-T) | -40 - 60 °C |
Operating relative humidity (H-H) | 0 - 95% |
Operating temperature (T-T) | -40 - 60 °C |
Width | 94.4 mm |
PACKAGE WEIGHT | 1.23 kg |
Depth | 84.7 mm |
Length | 288.4 mm |
Weight | 1 kg |
Quality of Service (QoS) support | Yes |
Streaming method | Multicast |
Bluetooth | No |
Networking standards | IEEE 802.1x |
Ethernet interface type | Fast Ethernet |
Ethernet LAN | Yes |
Wi-Fi | No |
Number of users | 20 user(s) |
Certification | LVD: EN62368-1; EMC: Electromagnetic Compatibility Directive 2014/30/EU; FCC: 47 CFR FCC Part 15, Subpart B; UL/CUL: UL62368-1 CAN/CSA C22.2 No. 62368-1-14 2023-01-18 |
Connectivity Technology | Wired |
Wide Dynamic Range (WDR) | 120 dB |
Placement supported | External / Internal |
Type | IP security camera |
Alarm input/output | Yes |
Day/night mode | Yes |
Number of Cameras | 1 |
Voice Codecs | PCM |
Two-way talk | Yes |
Speakerphone | Yes |
Number of microphones | 2 |
Built-in microphone | Yes |
Card reader integrated | Yes |
COMPATIBLE MEMORY CARDS | MicroSD (TransFlash) |
Maximum memory card size | 256 GB |
ROM capacity | 128 MB |
INTERNAL MEMORY | 512 MB |
Built-in HDD | No |
RCA input | 1 |
Ethernet LAN (RJ-45) ports | 1 |
Audio RCA outputs | 1 |
Lens viewing angle, vertical | 55° |
Lens viewing angle, diagonal | 125° |
Lens viewing angle, horizontal | 106° |
Tilt angle range | 0 - 90° |
Maximum Frame Rate | 30 fps |
White balance | Manual |
Camera shutter speed | 1/3 - 1/100000 s |
Angle of rotation | 360° |
Camera tilt control | Yes |
Adjustment shutter speed | Auto/Manual |
Camera pan control | Yes |
Pan range | 0 - 360° |
Minimum illumination | 0.004 lx |
Sensor type | CMOS |
Progressive Scan | Yes |
Optical sensor size | 25.4 / 2.8 mm (1 / 2.8") |
Number of sensors | 1 |
Video compression formats | M-JPEG |
Frame rate | 30 fps |
Supported graphics resolutions | 3840 x 2160 |
Gain control type | Auto/Manual |
Region of Interest (ROI) encoding | Yes |
Total megapixels | 8 MP |
Noise reduction | Yes |
Maximum Resolution | 3840 x 2160 pixels |
Noise reduction technology | 3D noise reduction |
Bit rate | H.264: 32 Kbps–8192 Kbps, H.265: 12 Kbps–8192 Kbps |
Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
Highlight Compensation (HLC) | Yes |
Back Light Compensation (BLC) | Yes |
Privacy masking | Yes |
Video streaming | Yes |
LED type | IR / White light LED |
Night vision distance | 30 m |
Number of illumination LEDs | 4 |
Night Vision | Yes |
Fixed focal length | 2.8 mm |
Observe distance (wide) | 36.4 m |
Number of lenses | 1 |
Maximum aperture number | 1 |
Closest focusing distance | 2 m |
Recognize distance (wide) | 18.2 m |
Identify distance (wide) | 9.1 m |
Detect distance (wide) | 91 m |
Warnings | The product contains electronic components; do not dispose of with the normal household waste. |
