| Form factor | Turret |
| Built-in microphone | Yes |
| Housing material | Metal |
| Mounting Type | Ceiling/wall |
| Product colour | White |
| International Protection (IP) code | IP67 |
| Power source type | DC, PoE |
| Power consumption (max) | 5 W |
| Power consumption (Power over Ethernet (PoE)) | 6.5 W |
| DC output current | 0.4 A |
| DC output voltage | 12 |
| Mirror | Yes |
| Video motion detection | Yes |
| PASSWORD PROTECTION | Yes |
| Heartbeat | Yes |
| Digital watermark | Yes |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating temperature (T-T) | -30 - 60 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage temperature (T-T) | -30 - 60 °C |
| Web-based management | Yes |
| Dedicated application | Hik-Connect (Android, iOS) |
| Weight | 340 g |
| PACKAGE WEIGHT | 560 g |
| Height | 89.2 mm |
| Package depth | 150 mm |
| Package width | 150 mm |
| Package height | 141 mm |
| Diameter | 11 cm |
| Networking standards | IEEE 802.3af |
| Bluetooth | No |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Quality of Service (QoS) support | Yes |
| Number of users | 32 user(s) |
| Certification | FCC: 47 CFR Part 15, Subpart B, EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014, RCM: AS/NZS CISPR 32: 2015, IC: ICES-003: Issue 7, UL 62368-1, IEC 62368-1: 2014+A11, CE-LVD: EN 62368-1: 2014/A11: 2017, IS 13252 (Part 1): 2010/IEC 60950-1: 2005, CE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/200 |
| Placement supported | Outdoor |
| Infrared (IR) cut-off filter | Yes |
| Type | IP security camera |
| Wide Dynamic Range (WDR) | Yes |
| Connectivity Technology | Wired |
| Day/night mode | Yes |
| Number of Cameras | 1 |
| Built-in HDD | No |
| Ethernet LAN (RJ-45) ports | 1 |
| Camera pan control | Yes |
| Angle of rotation | 360° |
| Pan range | 0 - 360° |
| Viewing angle, diagonal | 114° |
| Viewing angle, horizontal | 98° |
| Camera tilt control | Yes |
| Viewing angle, vertical | 54° |
| Camera shutter speed | 1/3 - 1/100000 s |
| Tilt angle range | 0 - 75° |
| Optical sensor size | 25.4 / 3 mm (1 / 3") |
| Sensor type | CMOS |
| Progressive Scan | Yes |
| Number of sensors | 1 |
| Image quality adjustment | White balance |
| Supported graphics resolutions | 640 x 480 (VGA) |
| Total megapixels | 4 MP |
| Frame rate | 20 fps |
| Privacy masking | Yes |
| Video compression formats | H.264+ |
| Noise reduction | Yes |
| Maximum Resolution | 2560 x 1440 pixels |
| Gain control type | Auto |
| Bit rate | 32 Kbps - 8 Mbps |
| Video streaming | Yes |
| Noise reduction technology | 3D noise reduction |
| Region of Interest (ROI) encoding | Yes |
| Night Vision | Yes |
| LED type | IR |
| Night vision distance | 30 m |
| Infra-red wavelength | 850 nm |
| Maximum aperture number | 1.6 |
| Fixed focal length | 2.8 mm |
| Number of lenses | 1 |
