| Mounting Type | Ceiling/wall |
| Housing material | Aluminium |
| Form factor | Bullet |
| International Protection (IP) code | IP67 |
| Product colour | White |
| DC output current | 0.5 A |
| DC output voltage | 12 |
| Power consumption (max) | 6 W |
| Power consumption (Power over Ethernet (PoE)) | 7.2 W |
| Power source type | DC, PoE |
| Intelligent Video Surveillance (IVS) system features | Face detection |
| Video motion detection | Yes |
| Security algorithms | TLS |
| Mirror | Yes |
| IP address filtering | Yes |
| Anti-flicker | Yes |
| Heartbeat | Yes |
| HTTPS encryption | Yes |
| PASSWORD PROTECTION | Yes |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating temperature (T-T) | -30 - 60 °C |
| Storage temperature (T-T) | -30 - 60 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Behavior analysis | Intrusion detection, Line crossing detection |
| Web-based management | Yes |
| Reset button | Yes |
| Diameter | 7 cm |
| Length | 16.2 cm |
| Package width | 216 mm |
| Package depth | 121 mm |
| Weight | 495 g |
| Package height | 118 mm |
| Number of users | 32 user(s) |
| Quality of Service (QoS) support | Yes |
| Ethernet interface type | Fast Ethernet |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Networking standards | IEEE 802.3af |
| Bluetooth | No |
| Certification | FCC (47 CFR 15, B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: 6, 2016); KC (KN 32: 2015, KN 35: 2015)UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013); BIS (IS 13252(1):2010+A1:2013+A2:2015)CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach ((EC) No 1907/2006) |
| Day/night mode | Yes |
| Placement supported | Outdoor |
| Type | IP security camera |
| Wide Dynamic Range (WDR) | Yes |
| Languages support | Multi |
| Number of languages | 33 |
| Connectivity Technology | Wired |
| Number of Cameras | 1 |
| Built-in microphone | No |
| COMPATIBLE MEMORY CARDS | MicroSD (TransFlash) |
| Built-in HDD | No |
| Card reader integrated | Yes |
| Maximum memory card size | 256 GB |
| Ethernet LAN (RJ-45) ports | 1 |
| Lens viewing angle, diagonal | 128° |
| Camera shutter speed | 1/3 - 1/100000 s |
| Camera pan control | Yes |
| Camera tilt control | Yes |
| Angle of rotation | 360° |
| Lens viewing angle, horizontal | 107° |
| Lens viewing angle, vertical | 57° |
| Pan range | 0 - 360° |
| Tilt angle range | 0 - 90° |
| Sensor type | CMOS |
| Number of sensors | 1 |
| Progressive Scan | Yes |
| Optical sensor size | 25.4 / 2.8 mm (1 / 2.8") |
| Video streaming | Yes |
| Video compression formats | M-JPEG |
| Privacy masking | Yes |
| Frame rate | 30 fps |
| Image quality adjustment | Saturation |
| Bit rate | 32 Kbps - 16 Mbps |
| Noise reduction | Yes |
| Region of Interest (ROI) encoding | Yes |
| Noise reduction technology | 3D noise reduction |
| Maximum Resolution | 3840 x 2160 pixels |
| Total megapixels | 8 MP |
| Supported graphics resolutions | 1920 x 1080 (HD 1080) |
| Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Back Light Compensation (BLC) | Yes |
| Highlight Compensation (HLC) | Yes |
| Night Vision | Yes |
| Night vision distance | 40 m |
| Infra-red wavelength | 850 nm |
| LED type | IR |
| Identify distance (wide) | 9 m |
| Maximum aperture number | 1.6 |
| Fixed focal length | 2.8 mm |
| Recognize distance (wide) | 17 m |
| Number of lenses | 1 |
