Iris | Yes |
Lens mount interface | M16 |
Output impedance | 100 Ω |
Product colour | Black |
Form factor | Turret |
Protection features | Dust resistant |
International Protection (IP) code | IP67 |
Housing material | Metal |
Mounting Type | Wall |
Power source type | DC, PoE |
Power consumption (max) | 9 W |
Power consumption (Power over Ethernet (PoE)) | 10.5 W |
DC output current | 0.75 A |
DC output voltage | 12 |
Security algorithms | EAP-MD5 |
HTTPS encryption | Yes |
Video motion detection | Yes |
PASSWORD PROTECTION | Yes |
IP address filtering | Yes |
Privacy protection | Yes |
Digital watermark | Yes |
Active tampering alarm | Yes |
Alarm input channels | 1 |
Mirror | Yes |
Heartbeat | Yes |
Alarm output channels | 1 |
Digest authentication | Yes |
Human and vehicle targets classification | Yes |
Password reset via email | Yes |
Automatic Network Replenishment (ANR) | Yes |
Pixel counter | Yes |
Audit log | Yes |
Network access storage (NAS) | Yes |
Storage relative humidity (H-H) | 0 - 95% |
Storage temperature (T-T) | -30 - 60 °C |
Operating temperature (T-T) | -30 - 60 °C |
Operating relative humidity (H-H) | 0 - 95% |
Web-based management | Yes |
Reset button | Yes |
Behavior analysis | Intrusion detection, Line crossing detection, Region entrance detection, Region exiting detection |
Weight | 820 g |
Height | 115.4 mm |
Diameter | 13.8 cm |
Bluetooth | No |
Quality of Service (QoS) support | Yes |
Live view | Yes |
Wi-Fi | No |
Client interoperability | iVMS-4200, Hik-Connect |
Number of users | 32 user(s) |
Ethernet interface type | Fast Ethernet |
Ethernet LAN | Yes |
User access level | Administrator, Operator, User |
Number of simultaneous live view channels | 6 channels |
Connectivity Technology | Wired |
Built-in light | Yes |
Wide Dynamic Range (WDR) | Yes |
Type | IP security camera |
Day/night mode | Yes |
Infrared (IR) cut-off filter | Yes |
Dynamic range | 130 dB |
Number of languages | 33 |
Languages support | Multi |
Alarm input/output | Yes |
Placement supported | Indoor & outdoor |
Package depth | 170 mm |
Package width | 170 mm |
PACKAGE WEIGHT | 1.32 kg |
Package height | 160 mm |
Number of Cameras | 1 |
Audio output channels | 1.0 channels |
Built-in microphone | Yes |
Audio formats supported | AAC-LC |
Built-in speaker(s) | Yes |
Audio input channels | 1.0 channels |
Signal-to-Noise Ratio (SNR) | 52 dB |
Sample rates | 8 - 48 kHz |
Bit rate range | 8 - 320 Kbit/s |
COMPATIBLE MEMORY CARDS | MicroSD (TransFlash) |
Card reader integrated | Yes |
Built-in HDD | No |
Maximum memory card size | 512 GB |
Ethernet LAN (RJ-45) ports | 1 |
Terminal block port | Yes |
Tilt angle range | 0 - 75° |
Minimum illumination | 0 lx |
Camera shutter speed | 1/3 - 1/100000 s |
Pan range | 0 - 360° |
Angle of rotation | 360° |
Lens viewing angle, horizontal | 108.8° |
Lens viewing angle, diagonal | 134.3° |
Lens viewing angle, vertical | 56.4° |
Number of Privacy masking areas | 4 |
Optical sensor size | 25.4 / 1.8 mm (1 / 1.8") |
Sensor type | CMOS |
Progressive Scan | Yes |
Number of sensors | 1 |
Supported graphics resolutions | 1920 x 1080 (HD 1080) |
Maximum Resolution | 3200 x 1800 pixels |
Image quality adjustment | Brightness |
Video compression formats | H.264 |
Privacy masking | Yes |
Back Light Compensation (BLC) | Yes |
Total megapixels | 6 MP |
Region of Interest (ROI) encoding | Yes |
Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
Highlight Compensation (HLC) | Yes |
Noise reduction technology | 3D noise reduction |
Noise reduction | Yes |
Frame rate | 30 fps |
Bit rate | 32 Kbps - 16 Mbps |
Video streaming | Yes |
Infra-red wavelength | 850 nm |
Night vision distance | 30 m |
LED type | IR/White |
Night Vision | Yes |
Detect distance | 89 m |
Fixed focus | Yes |
Recognize distance | 17 m |
Maximum aperture number | 1 |
Fixed focal length | 2.8 mm |
Observe distance | 35 m |
Identify distance | 8 m |
Number of lenses | 1 |
Warnings | The product contains electronic components; do not dispose of with the normal household waste. |
Compliance certificates | Low Voltage Directive (LVD) |
Sustainability compliance | Yes |
