Product colour | White |
International Protection (IP) code | IP67 |
Form factor | Bullet |
Mounting Type | Ceiling/wall |
Protection features | Water resistant |
Power consumption (max) | 8 W |
Power source type | DC, PoE |
DC output voltage | 12 |
Power consumption (Power over Ethernet (PoE)) | 9 W |
PASSWORD PROTECTION | Yes |
Password reset via email | Yes |
Intelligent Video Surveillance (IVS) system features | Scene change |
Heartbeat | Yes |
Active tampering alarm | Yes |
Motion sensor | Yes |
IP address filtering | Yes |
Mirror | Yes |
Anti-flicker | Yes |
HTTPS encryption | Yes |
Pixel counter | Y |
Digest authentication | Yes |
Human and vehicle targets classification | Yes |
Operating relative humidity (H-H) | 0 - 95% |
Operating temperature (T-T) | -30 - 60 °C |
Storage relative humidity (H-H) | 0 - 95% |
Storage temperature (T-T) | -30 - 60 °C |
Reset button | Yes |
Web browser | Yes |
Length | 28.9 cm |
Package height | 155 mm |
Diameter | 10.5 cm |
Weight | 1.17 kg |
Package width | 386 mm |
Package depth | 156 mm |
Number of users | 32 user(s) |
Ethernet interface type | Fast Ethernet |
Live view | Yes |
User access level | Administrator, Operator, User |
Ethernet LAN | Yes |
Wi-Fi | No |
Bluetooth | No |
Number of simultaneous live view channels | 6 channels |
Dynamic range | 130 dB |
Built-in light | Yes |
Type | IP security camera |
Wide Dynamic Range (WDR) | Yes |
Day/night mode | Yes |
Connectivity Technology | Wired |
Placement supported | Indoor & outdoor |
Alarm input/output | Yes |
Number of Cameras | 1 |
Audio system | 2-way |
Built-in microphone | Yes |
Built-in speaker(s) | Yes |
Built-in HDD | No |
COMPATIBLE MEMORY CARDS | SDHC |
Card reader integrated | Yes |
Ethernet LAN (RJ-45) ports | 1 |
Pan range | 0 - 360° |
Angle of rotation | 360° |
Camera shutter speed | 1/3 - 1/100000 s |
Tilt angle range | 0 - 90° |
Camera pan control | Yes |
Minimum illumination | 0.005 lx |
Camera tilt control | Yes |
Optical sensor size | 25.4 / 1.8 mm (1 / 1.8") |
Progressive Scan | Yes |
Sensor type | CMOS |
Number of sensors | 1 |
Privacy masking | Yes |
Image quality adjustment | Brightness |
Region of Interest (ROI) encoding | Yes |
Total megapixels | 4 MP |
Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
Supported graphics resolutions | 640 x 360 |
Back Light Compensation (BLC) | Yes |
Bit rate | 32 Kbps - 16 Mbps |
Video compression formats | H.265+ |
Maximum Resolution | 2688 x 1520 pixels |
Highlight Compensation (HLC) | Yes |
Frame rate | 30 fps |
Number of lenses | 1 |
Maximum aperture number | 1 |
Fixed focal length | 2.8 mm |
