| Services | |
| Type | IP-Sicherheitskamera |
| Unterstützte Positionierung | Innen & Außen |
| transmission technology | Kabelgebunden |
| Eigenschaft | Ressourcen-CD |
| Dynamischer Bereich | 140 dB |
| certification | CE/FCC/UL |
| Design | |
| form factor | Dome |
| attachment type | Zimmerdecke |
| Product color | Weiß |
| International degree of protection (IP code) | IP67 |
| IK-Kodex | IK10 |
| Country of origin | China |
| Camera | |
| viewing angle (horizontal) | 103° |
| viewing angle (vertical) | 54° |
| Lens viewing angle, diagonal | 124° |
| white balance | Auto |
| camera shutter speed | 1 - 1/100000 s |
| image sensor | |
| Image sensor size | 25,4 / 1,8 mm (1 / 1.8") |
| Sensor-Typ | CMOS |
| lens | |
| Optical zoom | 4,3x |
| night vision | |
| night vision distance | 150 m |
| LED Type | IR |
| Video | |
| Maximum resolution | 1920 x 1080 Pixel |
| total megapixels | 2 MP |
| Supported video formats | H.264, H.265, M-JPEG |
| Supported graphic resolutions | 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080) |
| Up to 30 frames per second | 60 fps |
| noise canceling technology | 3D-Rauschunterdrückung |
| gain control type | Auto |
| image quality adjustment | Helligkeit, Kontrast, Farbsättigung, Schärfe |
| transmission speed | 32Kbps~16Mbps |
| Audio | |
| voice codec | G.711, G.722, G.722.1, G.726, MP2L2 |
| network | |
| Supported network protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS,RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP,SNMP,IGMP,802.1X, QoS, IPv6, Bonjour |
| Anzahl der gleichzeitigen Live-View-Kanäle | 20 Kanäle |
| storage medium | |
| Compatible memory cards | MicroSD (TransFlash), SD, SDHC, SDXC |
| Max memory card size | 256 GB |
| connections and interfaces | |
| Number of Ethernet LAN ports (RJ-45) | 1 |
| headphone outputs | 1 |
| safety | |
| Intelligent Video Surveillance (IVS) system properties | Kreuzungslinie, Defokussieren, Gesichtserkennung, Eindringen, Erkennung des Eintritts in eine Region, Region exiting detection |
| management functions | |
| energy | |
| energy source | Gleichstrom, PoE |
| Power Consumption (Power over Ethernet (PoE)) | 8 W |
| operating conditions | |
| operating temperatur | -30 - 60 °C |
| Operating relative humidity | 0 - 95% |
| weight and dimensions | |
| broad | 133,1 mm |
| depth | 153,4 mm |
| height | 153,4 mm |
| Weight | 1,29 kg |
| package weight | 1,71 kg |
| packaging type | Box |
| scope of delivery | |
| number of cameras | 1 |
| Other functions | |
| Supported browser | IE8+, Chrome 31.0-44, Firefox 30.0-51, Safari 8.0+ |
| logistic data | |
| Goods tariff number (HS) | 85258900 |
| Shipping box width | 365 mm |
| Shipping carton length | 372 mm |
| Shipping carton height | 504 mm |
| Shipping carton weight | 13,7 kg |
| Number of products per shipping carton | 8 Stück(e) |
