Services | |
Type | IP-Sicherheitskamera |
Unterstützte Positionierung | Innen & Außen |
transmission technology | Kabelgebunden |
Eigenschaft | Ressourcen-CD |
Dynamischer Bereich | 140 dB |
certification | CE/FCC/UL |
Design | |
form factor | Dome |
attachment type | Zimmerdecke |
Product color | Weiß |
International degree of protection (IP code) | IP67 |
IK-Kodex | IK10 |
Country of origin | China |
Camera | |
viewing angle (horizontal) | 103° |
viewing angle (vertical) | 54° |
Lens viewing angle, diagonal | 124° |
white balance | Auto |
camera shutter speed | 1 - 1/100000 s |
image sensor | |
Image sensor size | 25,4 / 1,8 mm (1 / 1.8") |
Sensor-Typ | CMOS |
lens | |
Optical zoom | 4,3x |
night vision | |
night vision distance | 150 m |
LED Type | IR |
Video | |
Maximum resolution | 1920 x 1080 Pixel |
total megapixels | 2 MP |
Supported video formats | H.264, H.265, M-JPEG |
Supported graphic resolutions | 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080) |
Up to 30 frames per second | 60 fps |
noise canceling technology | 3D-Rauschunterdrückung |
gain control type | Auto |
image quality adjustment | Helligkeit, Kontrast, Farbsättigung, Schärfe |
transmission speed | 32Kbps~16Mbps |
Audio | |
voice codec | G.711, G.722, G.722.1, G.726, MP2L2 |
network | |
Supported network protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS,RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP,SNMP,IGMP,802.1X, QoS, IPv6, Bonjour |
Anzahl der gleichzeitigen Live-View-Kanäle | 20 Kanäle |
storage medium | |
Compatible memory cards | MicroSD (TransFlash), SD, SDHC, SDXC |
Max memory card size | 256 GB |
connections and interfaces | |
Number of Ethernet LAN ports (RJ-45) | 1 |
headphone outputs | 1 |
safety | |
Intelligent Video Surveillance (IVS) system properties | Kreuzungslinie, Defokussieren, Gesichtserkennung, Eindringen, Erkennung des Eintritts in eine Region, Region exiting detection |
management functions | |
energy | |
energy source | Gleichstrom, PoE |
Power Consumption (Power over Ethernet (PoE)) | 8 W |
operating conditions | |
operating temperatur | -30 - 60 °C |
Operating relative humidity | 0 - 95% |
weight and dimensions | |
broad | 133,1 mm |
depth | 153,4 mm |
height | 153,4 mm |
Weight | 1,29 kg |
package weight | 1,71 kg |
packaging type | Box |
scope of delivery | |
number of cameras | 1 |
Other functions | |
Supported browser | IE8+, Chrome 31.0-44, Firefox 30.0-51, Safari 8.0+ |
logistic data | |
Goods tariff number (HS) | 85258900 |
Shipping box width | 365 mm |
Shipping carton length | 372 mm |
Shipping carton height | 504 mm |
Shipping carton weight | 13,7 kg |
Number of products per shipping carton | 8 Stück(e) |
