Services | |
Type | IP-Sicherheitskamera |
Unterstützte Positionierung | Innen & Außen |
transmission technology | Kabelgebunden |
Eigenschaft | Schrauben enthalten |
Dynamischer Bereich | 120 dB |
Design | |
form factor | Dome |
attachment type | Zimmerdecke |
Product color | Weiß |
LED indicators | Aktivität, Leistung |
protective function | Vandalismussicher, Wetterfest |
International degree of protection (IP code) | IP67 |
Country of origin | China |
Camera | |
minimum lighting | 0 Lux |
viewing angle (horizontal) | 38 - 98° |
viewing angle (vertical) | 21 - 52° |
Lens viewing angle, diagonal | 43 - 115° |
camera shutter speed | 1/3 - 1/100000 s |
image sensor | |
Image sensor size | 25,4 / 2,7 mm (1 / 2.7") |
Sensor-Typ | CMOS |
lens | |
Optical zoom | 4x |
digital zoom | 16x |
number of lenses | 1 |
focal range | 2.8 - 12 mm |
Maximum f-number | 1,6 |
night vision | |
night vision distance | 30 m |
LED Type | IR |
Video | |
Maximum resolution | 1920 x 1080 Pixel |
total megapixels | 2 MP |
Video compression formats | H.264, H.265, M-JPEG |
Supported graphic resolutions | 640 x 360, 640 x 480 (VGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080) |
Up to 30 frames per second | 30 fps |
noise canceling technology | 3D-Rauschunterdrückung |
gain control type | Auto |
image quality adjustment | Helligkeit, Kontrast, Farbsättigung, Schärfe |
Audio | |
Audio-System | 1-Weg |
network | |
mesh standard | IEEE 802.1x, IEEE 802.3, IEEE 802.3af, IEEE 802.3u |
Supported network protocols | TCP(IPv6/v4), UDP, HTTP, HTTPS, DHCP, PPPoE, RTP, RTSP, DNS, DDNS, NTP, ICMP, ARP, IGMP, SMTP,FTP,SAMBA UPnP, SNMP, Bonjour |
storage medium | |
Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
Max memory card size | 256 GB |
connections and interfaces | |
Number of Ethernet LAN ports (RJ-45) | 1 |
safety | |
Intelligent Video Surveillance (IVS) system properties | Eindringen, Erkennung Leitungskreuzungen, Fehlendes Objekt |
energy | |
energy source | Gleichstrom, PoE |
Power consumption (max.) | 10 W |
Power Consumption (Power over Ethernet (PoE)) | 12 W |
DC output volts | 12 |
operating conditions | |
operating temperatur | -30 - 60 °C |
Operating relative humidity | 5 - 95% |
weight and dimensions | |
broad | 116 mm |
depth | 153 mm |
height | 153 mm |
Weight | 800 g |
package weight | 1,3 kg |
packaging type | Box |
sustainability | |
Konformitätsbescheinigungen | CE, Eidgenössische Kommunikationskommission (FCC), UKCA |
scope of delivery | |
number of cameras | 1 |
logistic data | |
Pallet length (gross) | 80 cm |
Pallet width (gross) | 120 cm |
Palettenhöhe (ugly) | 143 cm |
Customs tariff number (TARIC) | 8525890000 |
Goods tariff number (HS) | 852589 |
Shipping box width | 568 mm |
Shipping carton length | 345 mm |
Shipping carton height | 590 mm |
Shipping carton weight | 16 kg |
Number of products per shipping carton | 12 Stück(e) |
