Product colour | Black |
Degree of protection IK | IK10 |
Mounting Type | Ceiling |
International Protection (IP) code | IP67 |
Form factor | Dome |
Housing material | Metal, Plastic |
Power source type | DC, PoE |
Power consumption (Power over Ethernet (PoE)) | 6.4 W |
DC output voltage | 12 |
Power consumption (max) | 5.4 W |
Operating temperature (T-T) | -40 - 60 °C |
Storage temperature (T-T) | -40 - 60 °C |
Operating relative humidity (H-H) | 0 - 95% |
Web-based management | Yes |
Web browser | Yes |
Weight | 340 g |
Height | 81 mm |
Diameter | 10.9 cm |
Networking standards | IEEE 802.3af |
Bluetooth | No |
Number of users | 20 user(s) |
Quality of Service (QoS) support | Yes |
Ethernet interface type | Fast Ethernet |
Wi-Fi | No |
Mobile operating systems supported | iOS |
Certification | LVD: EN62368-1; EMC: Electromagnetic Compatibility Directive 2014/30/EU; FCC: 47 CFR FCC Part 15, Subpart B 2022-11-22 |
Connectivity Technology | Wired |
Placement supported | External / Internal |
Type | IP security camera |
Wide Dynamic Range (WDR) | 120 dB |
Signal-to-Noise Ratio (SNR) | 56 dB |
Number of Cameras | 1 |
Built-in microphone | Yes |
Audio formats supported | PCM |
ROM capacity | 128 MB |
Built-in HDD | No |
INTERNAL MEMORY | 256 MB |
Tilt angle range | 0 - 65° |
Lens viewing angle, diagonal | 125° |
Lens viewing angle, horizontal | 106° |
Lens viewing angle, vertical | 56° |
White balance | Street lamp |
Minimum illumination | 0.009 lx |
Pan range | 0 - 355° |
Adjustment shutter speed | Auto/Manual |
Camera shutter speed | 1/3 - 1/100000 s |
Number of sensors | 1 |
Sensor type | CMOS |
Optical sensor size | 25.4 / 2.7 mm (1 / 2.7") |
Progressive Scan | Yes |
Maximum Resolution | 3840 x 2160 pixels |
Supported graphics resolutions | 3840 x 2160 |
Mirror function | Yes |
Video streaming | Yes |
Gain control type | Auto/Manual |
Video compression formats | M-JPEG |
Bit rate | H.264: 32 kbps–8192 kbps H.265: 12 kbps–8192 kbps |
Region of Interest (ROI) encoding | Yes |
Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
Total megapixels | 8 MP |
Back Light Compensation (BLC) | Yes |
Highlight Compensation (HLC) | Yes |
Noise reduction | Yes |
Frame rate | 30 fps |
Noise reduction technology | 3D noise reduction |
Night Vision | Yes |
Night vision distance | 30 m |
Number of illumination LEDs | 3 |
LED type | IR |
Number of lenses | 1 |
Lens type | Fixed focal length lens |
Closest focusing distance | 1.3 m |
Maximum aperture number | 2 |
Focal length range | 2.8 mm |
