Mounting Type | Ceiling |
Housing material | Plastic |
Form factor | Turret |
Product colour | White |
International Protection (IP) code | IP67 |
DC output voltage | 12 |
Power consumption (typical) | 2.2 W |
Power source type | DC, PoE |
Intelligent Video Surveillance (IVS) system features | Intrusion |
Video motion detection | Yes |
Active tampering alarm | Yes |
Mirror | Yes |
Operating temperature (T-T) | -40 - 60 °C |
Storage temperature (T-T) | -40 - 60 °C |
Operating relative humidity (H-H) | 0 - 95% |
Web browser | Yes |
Length | 99.1 mm |
Weight | 480 g |
Diameter | 12.2 cm |
Number of users | 20 user(s) |
Streaming method | Multicast |
Ethernet LAN | Yes |
Bluetooth | No |
Quality of Service (QoS) support | Yes |
Wi-Fi | No |
Ethernet interface type | Fast Ethernet |
Mobile operating systems supported | iOS |
Certification | CE-LVD: EN62368-1;
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU |
Day/night mode | Yes |
Placement supported | Indoor & outdoor |
Connectivity Technology | Wired |
Type | IP security camera |
Wide Dynamic Range (WDR) | Yes |
PACKAGE WEIGHT | 620 g |
Number of Cameras | 1 |
Signal-to-Noise Ratio (SNR) | 56 dB |
ROM capacity | 128 MB |
COMPATIBLE MEMORY CARDS | MicroSD (TransFlash) |
Maximum memory card size | 256 GB |
Built-in HDD | No |
Ethernet LAN (RJ-45) ports | 1 |
Camera pan control | Yes |
Lens viewing angle, horizontal | 111° |
Camera tilt control | Yes |
Lens viewing angle, vertical | 58.5° |
Lens viewing angle, diagonal | 136° |
Minimum illumination | 0 lx |
White balance | Natural |
Pan range | 0 - 360° |
Angle of rotation | 360° |
Tilt angle range | 0 - 78° |
Camera shutter type | Electronic |
Adjustment shutter speed | Auto/Manual |
Camera shutter speed | 1/3 - 1/100000 s |
Number of sensors | 1 |
Sensor type | CMOS |
Progressive Scan | Yes |
Optical sensor size | 25.4 / 2.7 mm (1 / 2.7") |
Privacy masking | Yes |
Video compression formats | H.265 |
Smart IR | Yes |
Gain control type | Auto/Manual |
Video streaming | Yes |
Supported video modes | 720p |
Supported graphics resolutions | 2880 x 1620 |
Maximum Resolution | 2960 x 1688 pixels |
Bit rate | 32 Kbps - 8192 Kbps |
Back Light Compensation (BLC) | Yes |
Highlight Compensation (HLC) | Yes |
Total megapixels | 5 MP |
Noise reduction | Yes |
Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
Frame rate | 30 fps |
Region of Interest (ROI) encoding | Yes |
Noise reduction technology | 3D noise reduction |
Night Vision | Yes |
Number of illumination LEDs | 2 |
Night vision distance | 30 m |
LED type | IR/White |
Recognize distance (wide) | 12.8 m |
Maximum aperture number | 1 |
Identify distance (tele) | 7.8 m |
Identify distance | 6.4 m |
Identify distance (wide) | 6.4 m |
Number of lenses | 1 |
Observe distance (tele) | 31.1 m |
Recognize distance (tele) | 15.6 m |
Observe distance (wide) | 25.5 m |
Detect distance (tele) | 77.8 m |
Detect distance (wide) | 63.8 m |
Focal length range | 2.8, 3.6 mm |
Warnings | The product contains electronic components; do not dispose of with the normal household waste. |
