Type Fixed Dome/HDTV/Megapixel/Outdoor | Pixel Resolution 2 Mega Pixel | Focal Length 2.8 mm | IR Illumination | Sensor size 1/3” | Lens Mount M12 | Min. Illumination 0.0025 Lux | Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s | 1xRJ45 | Supports card capacities up to 256GB | Power options PoE/12V | Environment Outdoor | Operating temperature range -40°C~+60°C | Dimensions Φ110.7 mm × 88.7 mm
Description | 1/3” 2Megapixel CMOS, 1920×1080 @30FPS FullHD realtime
Minimum illumination: 0.025 lux @ F2.0 (Color, 30 IRE), 0.0025 lux @ F2.0 (B/W, 30 IRE)
True Day/Night (ICR), BLC/ HLC/ DWDR / 3D DNR
Fixed lend 2.8 mm Lens (100°)
Up to 30 meters IR Illumination, Smart IR
H.265+/H.265/H.264+/H.264 encoding, ONVIF (Profile S/Profile T); CGI; P2P; Genetec
Micro SD card (support max. 256 GB)
Wi-Fi IEEE802.11b/g/n 2.4–2.4835 GHz
Dome design, IK10, IP67, -40°C~+60°C, PoE / 12VDC power
Free IP monitoring software available
|
Vendor Homepage | www.dahuasecurity.com/products/All-Products/Network-Cameras/Wireless-Series/Wi-Fi-Series/2MP/IPC-HDBW1230DE-SW |
Model | IPC-HDBW1230DE-SW-0280B |
Camera design | Dome |
Network Camera Type | Fixed Dome/HDTV/Megapixel/Outdoor |
Pixel Resolution | 2 Mega Pixel |
Focal length | 2.8 mm |
IR Illumination | Yes |
Sensor size | 1/3” |
Lens Mount | M12 |
Min. Illumination | 0.0025 Lux |
Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s |
RJ45 | 1 |
Supports card capacities up to | 256GB |
Power Options | 12V/PoE |
Power consumption | 4.9 Watts |
Environment | Outdoor |
Operating temperature range | -40°C~+60°C |
Dimensions | Φ110.7 mm × 88.7 mm |
Unit Net Weight | 0.414 kg |
Unit Gross Weight | 0.646 kg |
Unit Box Width | 0.125 |
Unit Box Length | 0.15 |
Unit Box Height | 0.145 |
Full Description Line | Type Fixed Dome/HDTV/Megapixel/Outdoor|Pixel Resolution 2 Mega Pixel|Focal Length 2.8 mm|IR Illumination|Sensor size 1/3”|Lens Mount M12|Min. Illumination 0.0025 Lux|Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s|1xRJ45|Supports card capacities up to 256GB|Power options PoE/12V|Environment Outdoor|Operating temperature range -40°C~+60°C|Dimensions Φ110.7 mm × 88.7 mm |
Category Code | FNC |
