Type PTZ | Pixel Resolution 4 Mega Pixel | Focal Length 2.8 mm–12 mm | IR Illumination | Sensor size 1/2.8 ” CMOS | Min. Illumination 0.005 Lux | Electronic Shutter Speed 1/1 s–1/30,000 s | 1xMicroSD Card Slot | 1xRJ45 | Supports card capacities up to 512GB | Power options 12V | Environment Outdoor | Operating temperature range -30°C~+60°C | Dimensions 89 mm × Φ122 mm
Description | - Pan/Tilt/Zoom mini dome camera.
- 1/2.8 ” CMOS, 2560 × 1440 @ 30FPS max
- Minimum illumination: Color: 0.005 lux @ F1.6, B/W: 0.0005 lux @ F1.6
- True Day / Night with ICR Filter, BLC / HLC / DWDR / 3D DNR
- Varifocal lens 2.8 mm–12 mm (4x Optical zoom) (90.3°–29.4°)
- Pan Range: 0° ~ 355°; Tilt Range: 0° ~ 90°, auto flip 180°
- Preset Speed: 100° /s; Tilt: 60° /s; Presets: 300
- 16x digital zoom, Micro SD (Max 512GB)
- 802.11n; IEEE802.11b; 802.11g, 2.4G Wi-Fi
- H.265/H.264/+ MJPEG encoding, ONVIF(Profile S&G&T); P2P; CGI; SDK
- IP66 & IK10; -30°C~+60°C
- 12VDC only power, 4.8W max
- Free IP monitoring software available
|
Vendor Homepage | www.dahuasecurity.com/products/All-Products/PTZ-Cameras/WizSense-Series/SD2/SD22404DB-GNY |
Model | SD22404DB-GNY-W |
Camera design | Dome |
Network Camera Type | PTZ |
Pixel Resolution | 4 Mega Pixel |
Focal length | 2.8 mm–12 mm |
IR Illumination | Yes |
Sensor size | 1/2.8 ” CMOS |
Min. Illumination | 0.005 Lux |
Electronic Shutter Speed | 1/1 s–1/30,000 s |
MicroSD Card Slot | 1 |
RJ45 | 1 |
Supports card capacities up to | 512GB |
Power Options | 12V |
Power consumption | 4.8 Watts |
Environment | Outdoor |
Operating temperature range | -30°C~+60°C |
Dimensions | 89 mm × Φ122 mm |
Unit Net Weight | 0.5 kg |
Unit Gross Weight | 0.7 kg |
Full Description Line | Type PTZ|Pixel Resolution 4 Mega Pixel|Focal Length 2.8 mm–12 mm|IR Illumination|Sensor size 1/2.8 ” CMOS|Min. Illumination 0.005 Lux|Electronic Shutter Speed 1/1 s–1/30,000 s|1xMicroSD Card Slot|1xRJ45|Supports card capacities up to 512GB|Power options 12V|Environment Outdoor|Operating temperature range -30°C~+60°C|Dimensions 89 mm × Φ122 mm |
Category Code | FNC |
