Type HDTV/Megapixel/Outdoor | Pixel Resolution 5 Mega Pixel | Focal Length 2.8 mm | IR Illumination | Sensor size 1/2.7” | Microphone Built-in | Lens Mount M12 | Min. Illumination 0.0009 Lux | Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s | 1xAudio-In | 1xAudio-Out | 1xRJ45 | 1xAlarm In | 1xAlarm Out | Supports card capacities up to 256GB | Power options PoE/12V | Power supply requirements PoE / 12VDC power, 6.8W max | Environment Outdoor | Operating temperature range -40°C~+60°C | Colour White | Dimensions 99.1 mm × Φ121.9 mm
Description | 1/2.7” 5Megapixel progressive CMOS, 2960 × 1668 @ 30FPS max
Minimum illumination: 0.0009 lux @F1.6 (Color, 30 IRE); 0.0005 lux @F1.6 (B/W, 30 IRE); 0 lux (Illuminator on)
True Day/Night (ICR), BLC/HLC/True WDR 120 dB/3D DNR
2.8 mm fixed lens (111° HFOV)
Up to 50 meters IR LED Illumination
H.265; H.264; H.264H; H.264B; MJPEG encoding, ONVIF (Profile S/Profile G/Profile T); CGI
Built-in MIC, 1/1 Audio I/O, 1/1 Alarm I/O
Micro SD card up to 256GB supported
Metal core, IP67, -40°C~+60°C, PoE / 12VDC power, 6.8W max
With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, people counting, etc.
Free IP monitoring software available
|
Vendor Homepage | www.dahuasecurity.com/products/All-Products/Network-Cameras/WizMind-S-Series/5MP/IPC-HDW5541TM-ASE=S3 |
Model | IPC-HDW5541TM-ASE-0280B-S3 |
Camera design | Eyeball |
Network Camera Type | HDTV/Megapixel/Outdoor |
Pixel Resolution | 5 Mega Pixel |
Focal length | 2.8 mm |
IR Illumination | Yes |
Sensor size | 1/2.7” |
Microphone | Built-in |
Lens Mount | M12 |
Min. Illumination | 0.0009 Lux |
Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s |
Alarm In | 1 |
Alarm Out | 1 |
Audio-In | 1 |
Audio-Out | 1 |
RJ45 | 1 |
Supports card capacities up to | 256GB |
Power Options | 12V/PoE |
Power supply requirements | PoE / 12VDC power, 6.8W max |
Power consumption | 6.8 Watts |
Environment | Outdoor |
Operating temperature range | -40°C~+60°C |
Colour | White |
Dimensions | 99.1 mm × Φ121.9 mm |
Unit Net Weight | 0.5 kg |
Unit Gross Weight | 0.8 kg |
Unit Box Width | 0.15 |
Unit Box Length | 0.14 |
Unit Box Height | 0.13 |
Full Description Line | Type HDTV/Megapixel/Outdoor|Pixel Resolution 5 Mega Pixel|Focal Length 2.8 mm|IR Illumination|Sensor size 1/2.7”|Microphone Built-in|Lens Mount M12|Min. Illumination 0.0009 Lux|Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s|1xAudio-In|1xAudio-Out|1xRJ45|1xAlarm In|1xAlarm Out|Supports card capacities up to 256GB|Power options PoE/12V|Power supply requirements PoE / 12VDC power, 6.8W max|Environment Outdoor|Operating temperature range -40°C~+60°C|Colour White|Dimensions 99.1 mm × Φ121.9 mm |
Category Code | FNC |
