Services | |
Video input channels | 4 Kanäle |
Maximum resolution | 3840 x 2160 Pixel |
number of users | 32 Benutzer |
Supported video formats | H.264, H.265, MPEG4 |
Installed operating system | Eingebettetes LINUX |
throughput data rate | 80 Mbit/s |
hard disk | |
HDD capacity | 0 GB |
Maximum supported number of HDD | 1 |
Max storage capacity | 6 TB |
HDD size | 3.5" |
connections and interfaces | |
Number of Ethernet LAN ports (RJ-45) | 4 |
Eigenschaft | Handbuch auf CD |
Number of Power over Ethernet (PoE) ports | 4 |
Number of HDMI ports | 1 |
VGA (D-Sub) output connectors | 1 |
Number of USB 2.0 ports | 2 |
Audio RCA inputs | 1 |
Audio RCA outputs | 1 |
mesh standard | IEEE 802.3at |
Supported network protocols | TCP,UDP,IPv4,IPv6,Http,Https,SMTP,NTP,SNTP |
features | |
LED indicators | HDD, Leistung |
Product color | Schwarz |
Country of origin | China |
certification | CE, FCC, ISO9001, ISO14001 |
energy | |
Power consumption (standard operation) | 65 W |
system requirement | |
Supported mobile operating systems | Android, iOS |
Supported browser | Internet Explorer 9+ |
operating conditions | |
operating temperatur | -10 - 55 °C |
Operating relative humidity | 10 - 90% |
Technical details | |
Konformitätsbescheinigungen | RoHS |
weight and dimensions | |
broad | 240 mm |
depth | 48 mm |
height | 315 mm |
Weight | 1 kg |
packaging type | Box |
package weight | 1,15 kg |
scope of delivery | |
Supplied cables | AC |
logistic data | |
Shipping box width | 723 mm |
Shipping carton length | 503 mm |
Shipping carton height | 313 mm |
Shipping carton weight | 12,8 kg |
Number of products per shipping carton | 8 Stück(e) |
