Protection features | Waterproof |
International Protection (IP) code | IP67 |
Form factor | Bullet |
Housing material | Metal |
Product colour | White |
Mounting Type | Wall |
Weatherproof | Yes |
Power consumption (max) | 10.5 W |
Power source type | DC, PoE |
DC output voltage | 12 |
Power consumption (Power over Ethernet (PoE)) | 11.5 W |
Human and vehicle targets classification | Yes |
Built-in siren | Yes |
HTTPS encryption | Yes |
Motion sensor | Yes |
Video motion detection | Yes |
PASSWORD PROTECTION | Yes |
IP address filtering | Yes |
Alert notification type | Push notification |
Mirror | Yes |
Digest authentication | Yes |
Storage relative humidity (H-H) | 0 - 95% |
Operating temperature (T-T) | -30 - 60 °C |
Storage temperature (T-T) | -40 - 60 °C |
Operating relative humidity (H-H) | 0 - 95% |
Reset button | Yes |
Web-based management | Yes |
Web browser | Yes |
Cloud-managed | Yes |
Width | 74 mm |
Length | 184 mm |
Height | 74 mm |
Weight | 525 g |
Wi-Fi | No |
Ethernet LAN | Yes |
Networking standards | IEEE 802.3af |
Bluetooth | No |
Supported network protocols | TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP |
Live view | Yes |
Connectivity Technology | Wired |
Wide Dynamic Range (WDR) | Yes |
Type | IP security camera |
Day/night mode | Yes |
Placement supported | Outdoor |
Maximum operating distance | 85 m |
Infrared (IR) cut-off filter | Yes |
Dynamic range | 120 dB |
Remote viewing | Yes |
Package Type | Box |
Number of Cameras | 1 |
Manual | Yes |
Drilling template included | Yes |
Mounting Kit | Yes |
Screws included | Yes |
Bit rate range | 0 - 64 Kbit/s |
Built-in microphone | Yes |
Audio system | 2-way |
Audio output channels | 1.0 channels |
Audio input channels | 1.0 channels |
Audio formats supported | G.711 A-law |
Built-in speaker(s) | Yes |
Number of microphones | 1 |
Sample Rate | 8 kHz |
COMPATIBLE MEMORY CARDS | MicroSD (TransFlash) |
Maximum memory card size | 512 GB |
DC-in jack | Yes |
Ethernet LAN (RJ-45) ports | 1 |
Minimum illumination | 0 lx |
Lens viewing angle, vertical | 58.8° |
Lens viewing angle, horizontal | 111.4° |
Lens viewing angle, diagonal | 134° |
Tilt angle range | 0 - 90° |
Camera shutter speed | 1/3 to 1/10000 |
Sensor type | CMOS |
Progressive Scan | Yes |
Optical sensor size | 25.4 / 2.7 mm (1 / 2.7") |
Supported graphics resolutions | 2880 x 1620 |
Back Light Compensation (BLC) | Yes |
Bit rate | Main Stream: 256 Kbps to 8 Mbps, Sub-Stream: 64 Kbps to 512 Kbps |
Total megapixels | 8 MP |
Highlight Compensation (HLC) | Yes |
Maximum Resolution | 2880 x 1620 pixels |
Digital Wide Dynamic Range (DWDR) | Yes |
Video compression formats | H.264 |
Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
Image quality adjustment | Sharpness |
Video recording | Yes |
LED type | IR/White |
Night Vision | Yes |
Observe distance | 27 m |
Recognize distance | 13 m |
Fixed focal length | 2.8 mm |
Fixed focus | Yes |
Maximum aperture number | 1.6 |
Identify distance | 6 m |
Detect distance | 64 m |
