Form factor | Turret |
Product colour | White |
International Protection (IP) code | IP67 |
Mounting Type | Ceiling |
Housing material | Metal |
Protection features | Waterproof |
Weatherproof | Yes |
Power source type | DC, PoE |
Power consumption (max) | 11 W |
DC output voltage | 12 |
Power consumption (Power over Ethernet (PoE)) | 12 W |
IP address filtering | Yes |
Video motion detection | Yes |
HTTPS encryption | Yes |
Alert notification type | Push notification |
Motion sensor | Yes |
PASSWORD PROTECTION | Yes |
Mirror | Yes |
Built-in siren | Yes |
Digest authentication | Yes |
Operating temperature (T-T) | -30 - 60 °C |
Storage relative humidity (H-H) | 0 - 95% |
Operating relative humidity (H-H) | 0 - 95% |
Storage temperature (T-T) | -40 - 60 °C |
Reset button | Yes |
Web browser | Yes |
Cloud-managed | Yes |
Weight | 480 g |
Length | 111 mm |
Height | 83.7 mm |
Width | 111 mm |
Networking standards | IEEE 802.3at |
Bluetooth | No |
Ethernet LAN | Yes |
Live view | Yes |
Wi-Fi | No |
Supported network protocols | TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP |
Connectivity Technology | Wired |
Type | IP security camera |
Wide Dynamic Range (WDR) | Yes |
Maximum operating distance | 80 m |
Dynamic range | 120 dB |
Infrared (IR) cut-off filter | Yes |
Placement supported | Outdoor |
Remote viewing | Yes |
Day/night mode | Yes |
Package Type | Box |
Manual | Yes |
Mounting Kit | Yes |
Number of Cameras | 1 |
Screws included | Yes |
Drilling template included | Yes |
Audio output channels | 1.0 channels |
Audio system | 2-way |
Built-in microphone | Yes |
Audio formats supported | G.711 A-law |
Built-in speaker(s) | Yes |
Number of microphones | 1 |
Audio input channels | 1.0 channels |
Sample Rate | 8 kHz |
Bit rate range | 0 - 64 Kbit/s |
COMPATIBLE MEMORY CARDS | MicroSD (TransFlash) |
Maximum memory card size | 512 GB |
Ethernet LAN (RJ-45) ports | 1 |
Tilt angle range | 0 - 90° |
Camera shutter speed | 1/3 to 1/10000 |
Minimum illumination | 0 lx |
Lens viewing angle, vertical | 41.8° |
Lens viewing angle, horizontal | 80.4° |
Lens viewing angle, diagonal | 98.7° |
Sensor type | CMOS |
Progressive Scan | Yes |
Optical sensor size | 25.4 / 2.7 mm (1 / 2.7") |
Supported graphics resolutions | 2304 x 1296 |
Maximum Resolution | 2688 x 1520 pixels |
Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
Highlight Compensation (HLC) | Yes |
Video recording | Yes |
Video compression formats | H.265+ |
Back Light Compensation (BLC) | Yes |
Image quality adjustment | Saturation |
Digital Wide Dynamic Range (DWDR) | Yes |
Bit rate | Main Stream: 256 Kbps to 6 Mbps, Sub-Stream: 64 Kbps to 512 Kbps |
Total megapixels | 4 MP |
LED type | IR/White |
Night Vision | Yes |
Observe distance | 33 m |
Fixed focus | Yes |
Fixed focal length | 4 mm |
Recognize distance | 16 m |
Maximum aperture number | 1.6 |
Detect distance | 80 m |
Identify distance | 8 m |
Digital Wide Dynamic Range (DWDR) (panoramic camera) | Yes |
Signal-to-Noise Ratio (SNR) (panoramic camera) | 52 dB |
Sensor type (panoramic camera) | CMOS |
