Product colour | White |
Form factor | Dome |
Weatherproof | Yes |
Housing material | Metal |
I code | IK10 |
Protection features | Waterproof |
Mounting Type | Ceiling |
International Protection (IP) code | IP67 |
Power source type | DC, PoE |
Power consumption (Power over Ethernet (PoE)) | 12 W |
DC output voltage | 12 |
Power consumption (max) | 10.8 W |
Alert notification type | Push notification |
Mirror | Yes |
Built-in siren | Yes |
Digest authentication | Yes |
Human and vehicle targets classification | Yes |
IP address filtering | Yes |
Intelligent Video Surveillance (IVS) system features | Human detection |
Video motion detection | Yes |
Motion sensor | Yes |
HTTPS encryption | Yes |
Detection distance | 200 m |
PASSWORD PROTECTION | Yes |
Operating relative humidity (H-H) | 0 - 95% |
Operating temperature (T-T) | -30 - 60 °C |
Storage temperature (T-T) | -40 - 60 °C |
Storage relative humidity (H-H) | 0 - 95% |
Reset button | Yes |
Web-based management | Yes |
Cloud-managed | Yes |
Web browser | Yes |
Weight | 775 g |
Depth | 129.9 mm |
Width | 129.9 mm |
Height | 102.5 mm |
Bluetooth | No |
Networking standards | IEEE 802.3af |
Live view | Yes |
Ethernet LAN | Yes |
Supported network protocols | TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP |
Wi-Fi | No |
Type | IP security camera |
Connectivity Technology | Wired |
Dynamic range | 120 dB |
Remote viewing | Yes |
Infrared (IR) cut-off filter | Yes |
Maximum operating distance | 200 m |
Wide Dynamic Range (WDR) | Yes |
Day/night mode | Yes |
Placement supported | Outdoor |
Package Type | Box |
Manual | Yes |
Number of Cameras | 1 |
Audio system | 2-way |
Audio output channels | 1.0 channels |
Built-in microphone | Yes |
Sample Rate | 8 kHz |
Bit rate range | 0 - 64 Kbit/s |
Audio formats supported | G.711 A-law |
Number of microphones | 1 |
Audio input channels | 1.0 channels |
Built-in speaker(s) | Yes |
COMPATIBLE MEMORY CARDS | MicroSD (TransFlash) |
Maximum memory card size | 512 GB |
DC-in jack | Yes |
Ethernet LAN (RJ-45) ports | 1 |
Tilt angle range | 0 - 75° |
Camera pan control | Yes |
Camera tilt control | Yes |
Lens viewing angle, horizontal | 29.6 - 102° |
Lens viewing angle, vertical | 16.8 - 53.8° |
Lens viewing angle, diagonal | 34.1 - 122.8° |
Minimum illumination | 0 lx |
Camera shutter speed | 1/3 to 1/10000 |
Sensor type | CMOS |
Progressive Scan | Yes |
Optical sensor size | 25.4 / 2.9 mm (1 / 2.9") |
Supported graphics resolutions | 2304 x 1296 |
Maximum Resolution | 2688 x 1520 pixels |
Video recording | Yes |
Video compression formats | H.264 |
Bit rate | Main Stream: H.265+/H.265/H.264+/H.264, Sub-Stream: H.265/H.264 |
Image quality adjustment | Saturation |
Digital Wide Dynamic Range (DWDR) | Yes |
Back Light Compensation (BLC) | Yes |
Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
Highlight Compensation (HLC) | Yes |
Total megapixels | 4 MP |
LED type | IR/White |
Night Vision | Yes |
Detect distance | 200 m |
Auto focus | Yes |
Identify distance | 21 m |
Focus | Motorized |
Observe distance | 84 m |
Optical zoom | 5x |
Maximum aperture number | 1.6 |
Recognize distance | 40 m |
