Services | |
Type | IP-Sicherheitskamera |
Unterstützte Positionierung | Innen & Außen |
transmission technology | Kabelgebunden |
Eigenschaft | Montageset |
certification | CE, BSMI, VCCI, ONVIF |
Design | |
form factor | Dome |
attachment type | Decke/Wand |
Product color | Schwarz, Weiß |
housing material | Kunststoff |
International degree of protection (IP code) | IP67 |
IK-Kodex | IK10 |
Camera | |
minimum lighting | 0,005 Lux |
rotation angle | 360° |
viewing angle (horizontal) | 79.7° |
viewing angle (vertical) | 42.9° |
Lens viewing angle, diagonal | 93.9° |
tilt angle range | 0 - 85° |
swivel range | 0 - 360° |
image sensor | |
Image sensor size | 25,4 / 3 mm (1 / 3") |
Sensor-Typ | CMOS |
lens | |
number of lenses | 1 |
Objektivdurchmesser | 4 mm |
night vision | |
night vision distance | 30 m |
LED Type | IR |
Number of illumination LEDs | 1 |
infrared wavelength | 850 nm |
Video | |
Maximum resolution | 2560 x 1440 Pixel |
total megapixels | 4 MP |
Video compression formats | H.264, H.264+, H.265, H.265+ |
Supported graphic resolutions | 320 x 240, 352 x 288, 640 x 480 (VGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2048 x 1280, 2304 x 1296, 2560 x 1440 |
Up to 30 frames per second | 30 fps |
noise canceling technology | 3D-Rauschunterdrückung |
image quality adjustment | Helligkeit, Kontrast, Spiegel, Farbsättigung, Schärfe |
transmission speed | 64 Kbps - 4 Mbps |
Audio | |
network | |
Ethernet interfaces type | Schnelles Ethernet |
Supported network protocols | TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS |
Anzahl der gleichzeitigen Live-View-Kanäle | 3 Kanäle |
storage medium | |
Compatible memory cards | MicroSD (TransFlash) |
Max memory card size | 256 GB |
connections and interfaces | |
Number of Ethernet LAN ports (RJ-45) | 1 |
safety | |
management functions | |
Managementsoftware | VIGI App, VIGI Security Manager, VIGI NVR |
energy | |
energy source | Gleichstrom, PoE |
Power consumption (max.) | 5,4 W |
operating conditions | |
operating temperatur | -30 - 60 °C |
weight and dimensions | |
broad | 115 mm |
depth | 115 mm |
height | 86 mm |
features | |
Grundlegendes Ereignis | Motion Detection, Camera Tampering Detection, Exception |
package weight | 470 g |
sustainability | |
Konformitätsbescheinigungen | CE |
scope of delivery | |
number of cameras | 1 |
