| Services | |
| Type | IP-Sicherheitskamera |
| Unterstützte Positionierung | Innen & Außen |
| transmission technology | Kabelgebunden |
| Eigenschaft | Digest-Authentifizierung |
| Dynamischer Bereich | 120 dB |
| Design | |
| form factor | Turret |
| attachment type | Decke/Wand |
| Product color | Weiß |
| housing material | Metall, Kunststoff |
| International degree of protection (IP code) | IP67 |
| Camera | |
| minimum lighting | 0,005 Lux |
| viewing angle (horizontal) | 100° |
| viewing angle (vertical) | 54° |
| Lens viewing angle, diagonal | 118° |
| tilt angle range | 0 - 85° |
| swivel range | 0 - 360° |
| camera shutter speed | 1/3 - 1/10000 s |
| Anzahl der Bereiche zur Verdeckung der Privatsphäre | 4 |
| image sensor | |
| Image sensor size | 25,4 / 2,7 mm (1 / 2.7") |
| Sensor-Typ | CMOS |
| lens | |
| number of lenses | 1 |
| distance determination | 64 m |
| Abstandsbeobachtung | 27 m |
| Abstandserkennung | 13 m |
| Objektivdurchmesser | 2,8 mm |
| focal range | 2.8 mm |
| Maximum f-number | 1,6 |
| Abstandsermittlung | 6 m |
| Minimum f-number | 1,6 |
| Fixed focal length | 2,8 mm |
| night vision | |
| night vision distance | 30 m |
| LED Type | IR/Weiß |
| Number of illumination LEDs | 4 |
| infrared wavelength | 850 nm |
| Video | |
| Maximum resolution | 2688 x 1520 Pixel |
| total megapixels | 4 MP |
| Video compression formats | H.264, H.264+, H.265, H.265+ |
| Supported graphic resolutions | 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2048 x 1280, 2304 x 1296, 2550 x 1440, 2688 x 1520 |
| Up to 30 frames per second | 60 fps |
| noise canceling technology | 3D-Rauschunterdrückung |
| Bitratenkontrolle | Konstante Bitrate (CBR), Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| transmission speed | 6 Mbps |
| Audio | |
| Samplerate | 8 kHz |
| Noise Ratio (SNR) | 52 dB |
| Bereich der Bitrate | 64 - 64 Kbit/s |
| network | |
| Ethernet interfaces type | Schnelles Ethernet |
| Supported network protocols | TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS |
| connections and interfaces | |
| Number of Ethernet LAN ports (RJ-45) | 1 |
| safety | |
| energy | |
| energy source | Gleichstrom, PoE |
| Power consumption (max.) | 10,1 W |
| operating conditions | |
| operating temperatur | -30 - 60 °C |
| Storage temperature range | -40 - 60 °C |
| Operating relative humidity | 0 - 95% |
| humidity during storage | 0 - 95% |
| weight and dimensions | |
| broad | 111 mm |
| depth | 111 mm |
| height | 83,7 mm |
| Weight | 480 g |
| scope of delivery | |
| number of cameras | 1 |
