| Services | |
| Type | IP-Sicherheitskamera |
| Unterstützte Positionierung | Innen & Außen |
| transmission technology | Kabelgebunden |
| Eigenschaft | Montageset |
| light output | 0,005 lm |
| certification | RCM, BSMI, VCCI, NTRA, KC |
| Design | |
| form factor | Turret |
| attachment type | Decke/Wand |
| Product color | Schwarz, Weiß |
| housing material | Kunststoff |
| International degree of protection (IP code) | IP66 |
| Camera | |
| viewing angle (horizontal) | 80° |
| viewing angle (vertical) | 43° |
| Lens viewing angle, diagonal | 94° |
| tilt angle range | 0 - 120° |
| incline speed | 44 °/Sekunde |
| swivel range | 0 - 348° |
| Webcam - Pan speed | 44 °/Sekunde |
| camera shutter speed | 1/3 - 1/10000 s |
| Anzahl der Bereiche zur Verdeckung der Privatsphäre | 4 |
| image sensor | |
| Image sensor size | 25,4 / 3,06 mm (1 / 3.06") |
| Sensor-Typ | CMOS |
| lens | |
| number of lenses | 1 |
| distance determination | 80 m |
| Abstandsbeobachtung | 33 m |
| Abstandserkennung | 16 m |
| Objektivdurchmesser | 4 mm |
| Maximum f-number | 1,6 |
| Abstandsermittlung | 8 m |
| Minimum f-number | 1,6 |
| night vision | |
| night vision distance | 30 m |
| LED Type | IR/Weiß |
| Number of illumination LEDs | 4 |
| Video | |
| Maximum resolution | 2560 x 1440 Pixel |
| total megapixels | 4 MP |
| Video compression formats | H.264, H.264+, H.265, H.265+ |
| Supported graphic resolutions | 320 x 240, 352 x 288, 640 x 480 (VGA), 1920 x 1080 (HD 1080), 2048 x 1280, 2304 x 1296, 2560 x 1440 |
| Up to 30 frames per second | 30 fps |
| noise canceling technology | 3D-Rauschunterdrückung |
| image quality adjustment | Helligkeit, Kontrast, Spiegel, Farbsättigung, Schärfe |
| Bitratenkontrolle | Konstante Bitrate (CBR), Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| transmission speed | 256 Kbps - 4 Mbps |
| Audio | |
| Samplerate | 8 kHz |
| Noise Ratio (SNR) | 52 dB |
| Bereich der Bitrate | 64 - 64 Kbit/s |
| network | |
| Ethernet interfaces type | Schnelles Ethernet |
| Supported network protocols | TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS |
| SIM card type | NanoSIM |
| 4G-Standards | LTE-TDD & LTE-FDD |
| 3G standards | WCDMA |
| Anzahl der gleichzeitigen Live-View-Kanäle | 3 Kanäle |
| storage medium | |
| Compatible memory cards | MicroSD (TransFlash) |
| Max memory card size | 256 GB |
| connections and interfaces | |
| Number of Ethernet LAN ports (RJ-45) | 1 |
| safety | |
| Intelligent Video Surveillance (IVS) system properties | Erkennung von Menschen |
| management functions | |
| Verhaltensanalyse | Erkennung von Eindringlingen, Erkennung Leitungskreuzungen |
| energy | |
| energy source | Gleichstrom |
| DC output volts | 12 |
| operating conditions | |
| operating temperatur | -30 - 60 °C |
| Storage temperature range | -40 - 60 °C |
| Operating relative humidity | 0 - 95% |
| humidity during storage | 0 - 95% |
| weight and dimensions | |
| broad | 120 mm |
| depth | 182 mm |
| height | 201 mm |
| Weight | 690 g |
| features | |
| Grundlegendes Ereignis | Motion Detection, Camera Tampering Detection, Exception |
| package weight | 1,16 kg |
| sustainability | |
| Konformitätsbescheinigungen | CE, RoHS |
| scope of delivery | |
| number of cameras | 1 |
