| Services | |
| Type | IP-Sicherheitskamera |
| Unterstützte Positionierung | Innen & Außen |
| transmission technology | Kabelgebunden |
| Eigenschaft | Smartphone Fernsteuerung |
| PTZ-Modi | Automatischer Suchlauf, Preset-Punkt |
| certification | CE, EAC, UKCA, RCM, Triman, BSMI, VCCI, FCC, IC |
| Design | |
| form factor | Turret |
| attachment type | Decke/Wand |
| Product color | Schwarz, Weiß |
| housing material | Kunststoff |
| International degree of protection (IP code) | IP66 |
| Camera | |
| viewing angle (horizontal) | 104° |
| viewing angle (vertical) | 55° |
| Lens viewing angle, diagonal | 127° |
| tilt angle range | 0 - 105° |
| incline speed | 44 °/Sekunde |
| swivel range | 0 - 348° |
| Webcam - Pan speed | 44 °/Sekunde |
| image sensor | |
| number of sensors | 1 |
| Image sensor size | 25,4 / 3 mm (1 / 3") |
| Sensor-Typ | CMOS |
| lens | |
| number of lenses | 1 |
| distance determination | 63 m |
| Abstandsbeobachtung | 26 m |
| Abstandserkennung | 13 m |
| Objektivdurchmesser | 4 mm |
| Abstandsermittlung | 6 m |
| night vision | |
| night vision distance | 30 m |
| LED Type | IR |
| Video | |
| Maximum resolution | 2688 x 1520 Pixel |
| total megapixels | 4 MP |
| Video compression formats | H.264, H.264+, H.265, H.265+ |
| Supported graphic resolutions | 320 x 240, 352 x 288, 640 x 480 (VGA), 704 x 576, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2048 x 1280, 2304 x 1296, 2560 x 1440, 2688 x 1520 |
| Up to 30 frames per second | 30 fps |
| image quality adjustment | Helligkeit, Kontrast, DNR, Spiegel, Farbsättigung, Schärfe |
| transmission speed | 256 Kbps - 6 Mbps |
| Audio | |
| Audio-System | 2-Wege |
| Audio input channels | 1 Kanäle |
| audio channels | 1 Kanäle |
| Bereich der Bitrate | 0 - 64 Kbit/s |
| sample rates | 0 - 8 kHz |
| network | |
| Ethernet interfaces type | Schnelles Ethernet |
| Supported network protocols | TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS |
| Anzahl der gleichzeitigen Live-View-Kanäle | 3 Kanäle |
| storage medium | |
| Compatible memory cards | MicroSD (TransFlash) |
| Max memory card size | 256 GB |
| connections and interfaces | |
| Number of Ethernet LAN ports (RJ-45) | 1 |
| safety | |
| Intelligent Video Surveillance (IVS) system properties | Verlassenes Objekt, Erkennung von Menschen, Fahrzeugerkennung |
| management functions | |
| Verhaltensanalyse | Erkennung von Eindringlingen, Erkennung Leitungskreuzungen, Region exiting detection |
| energy | |
| energy source | Gleichstrom, PoE |
| Power consumption (max.) | 13,13 W |
| Power Consumption (Power over Ethernet (PoE)) | 16,47 W |
| DC output volts | 12 |
| operating conditions | |
| operating temperatur | -30 - 60 °C |
| Storage temperature range | -40 - 60 °C |
| Operating relative humidity | 0 - 95% |
| humidity during storage | 0 - 95% |
| weight and dimensions | |
| broad | 120 mm |
| depth | 172 mm |
| height | 203 mm |
| scope of delivery | |
| number of cameras | 1 |
