| Services | |
| Type | IP-Sicherheitskamera |
| Unterstützte Positionierung | Innen & Außen |
| transmission technology | Verkabelt & Kabellos |
| certification | RCM, BSMI, VCCI, NCC, JRF, KC |
| Design | |
| form factor | Turret |
| attachment type | Decke/Wand |
| Product color | Schwarz, Weiß |
| housing material | Kunststoff |
| International degree of protection (IP code) | IP66 |
| Camera | |
| Eigenschaft | Montageset |
| viewing angle (horizontal) | 79° |
| viewing angle (vertical) | 43° |
| Lens viewing angle, diagonal | 93° |
| tilt angle range | 0 - 120° |
| incline speed | 44 °/Sekunde |
| swivel range | 0 - 350° |
| Webcam - Pan speed | 44 °/Sekunde |
| image sensor | |
| Image sensor size | 25,4 / 3 mm (1 / 3") |
| Sensor-Typ | CMOS |
| lens | |
| number of lenses | 1 |
| distance determination | 80 m |
| Abstandsbeobachtung | 33 m |
| Abstandserkennung | 16 m |
| Objektivdurchmesser | 4 mm |
| Abstandsermittlung | 8 m |
| night vision | |
| night vision distance | 30 m |
| LED Type | IR |
| infrared wavelength | 850 nm |
| Video | |
| Maximum resolution | 2560 x 1440 Pixel |
| total megapixels | 4 MP |
| Video compression formats | H.264, H.264+, H.265, H.265+ |
| Supported graphic resolutions | 320 x 240, 352 x 288, 640 x 480 (VGA), 1920 x 1080 (HD 1080), 2048 x 1280, 2304 x 1296, 2560 x 1440 |
| Up to 30 frames per second | 30 fps |
| noise canceling technology | 3D-Rauschunterdrückung |
| image quality adjustment | Helligkeit, Kontrast, Spiegel, Farbsättigung, Schärfe |
| transmission speed | 256 Kbps - 4 Mbps |
| Audio | |
| network | |
| Ethernet interfaces type | Schnelles Ethernet |
| Supported network protocols | TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS |
| WLAN-Standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Anzahl der gleichzeitigen Live-View-Kanäle | 3 Kanäle |
| storage medium | |
| Compatible memory cards | MicroSD (TransFlash) |
| Max memory card size | 256 GB |
| connections and interfaces | |
| Number of Ethernet LAN ports (RJ-45) | 1 |
| safety | |
| Supported security algorithms | WPA, WPA2-PSK |
| Intelligent Video Surveillance (IVS) system properties | Erkennung von Menschen |
| management functions | |
| Verhaltensanalyse | Erkennung von Eindringlingen, Erkennung Leitungskreuzungen |
| energy | |
| energy source | Gleichstrom |
| DC output volts | 12 |
| operating conditions | |
| operating temperatur | -30 - 60 °C |
| weight and dimensions | |
| broad | 120 mm |
| depth | 172 mm |
| height | 198 mm |
| features | |
| Grundlegendes Ereignis | Motion Detection, Camera Tampering Detection, Exception |
| package weight | 1,21 kg |
| sustainability | |
| Konformitätsbescheinigungen | CE, RoHS |
| scope of delivery | |
| number of cameras | 1 |
