Services | |
Type | IP-Sicherheitskamera |
Unterstützte Positionierung | Drinnen |
transmission technology | Kabellos |
Eigenschaft | Schrauben enthalten |
radio frequency | 2400 MHz |
certification | RCC, CE |
Design | |
form factor | Cube |
Product color | Weiß |
LED indicators | System |
Camera | |
Angle of view (FOV) | 105° |
image sensor | |
number of sensors | 1 |
Image sensor size | 25,4 / 3,2 mm (1 / 3.2") |
lens | |
number of lenses | 1 |
Maximum f-number | 2 |
Fixed focal length | 3,3 mm |
night vision | |
night vision distance | 9 m |
LED Type | IR |
infrared wavelength | 850 nm |
Video | |
Maximum resolution | 1920 x 1080 Pixel |
Supported video formats | H.264 |
Video compression formats | H.264 |
Supported video modes | 1080p |
Up to 30 frames per second | 15 fps |
Audio | |
Audio-System | 2-Wege |
network | |
mesh standard | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
Supported network protocols | TCP/IP, DHCP, ARP, ICMP ,DNS, NTP, HTTP, HTTPS, UDP, ONVIF, RTSP |
WLAN-Standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
Wi-Fi data rate (max) | 150 Mbit/s |
storage medium | |
Compatible memory cards | MicroSD (TransFlash) |
Max memory card size | 128 GB |
connections and interfaces | |
safety | |
Supported security algorithms | 128-bit AES, SSL/TLS, WEP, WPA, WPA2-PSK |
management functions | |
energy | |
energy source | AC, Gleichstrom |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
DC output volts | 9 |
DC output current | 0,6 A |
operating conditions | |
operating temperatur | 0 - 40 °C |
Storage temperature range | -40 - 70 °C |
Operating relative humidity | 10 - 90% |
humidity during storage | 5 - 90% |
weight and dimensions | |
broad | 67,6 mm |
depth | 54,6 mm |
height | 98,9 mm |
package weight | 240 g |
sustainability | |
Konformitätsbescheinigungen | RoHS |
scope of delivery | |
number of cameras | 1 |
