| Services | |
| Type | IP-Sicherheitskamera |
| Unterstützte Positionierung | Draußen |
| transmission technology | Verkabelt & Kabellos |
| Eigenschaft | Reset-Knopf |
| certification | CE, NCC |
| Design | |
| form factor | Cube |
| attachment type | Wand |
| Product color | Weiß |
| LED indicators | System |
| protective function | Staubresistent, Regensicher |
| International degree of protection (IP code) | IP66 |
| Camera | |
| Angle of view (FOV) | 104° |
| image sensor | |
| number of sensors | 1 |
| Image sensor size | 25,4 / 2,7 mm (1 / 2.7") |
| lens | |
| number of lenses | 1 |
| Maximum f-number | 2,2 |
| Fixed focal length | 3,89 mm |
| night vision | |
| night vision distance | 30 m |
| LED Type | IR |
| infrared wavelength | 850 nm |
| Video | |
| Maximum resolution | 2304 x 1296 Pixel |
| total megapixels | 3 MP |
| Supported video formats | H.264 |
| Up to 30 frames per second | 15 fps |
| Audio | |
| Audio-System | 2-Wege |
| network | |
| mesh standard | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| WLAN-Standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| storage medium | |
| Compatible memory cards | MicroSD (TransFlash) |
| Max memory card size | 128 GB |
| connections and interfaces | |
| Number of Ethernet LAN ports (RJ-45) | 1 |
| safety | |
| Supported security algorithms | 128-bit AES, SSL/TLS, WPA, WPA2-PSK |
| management functions | |
| energy | |
| energy source | AC, Gleichstrom |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| DC output volts | 9 |
| DC output current | 0,6 A |
| operating conditions | |
| operating temperatur | 0 - 40 °C |
| Storage temperature range | -40 - 70 °C |
| Operating relative humidity | 10 - 90% |
| humidity during storage | 5 - 90% |
| weight and dimensions | |
| broad | 142,3 mm |
| depth | 103,4 mm |
| height | 64,3 mm |
| package weight | 420 g |
| scope of delivery | |
| number of cameras | 1 |
| logistic data | |
| Goods tariff number (HS) | 85258900 |
