International Protection (IP) code | IP66 |
Form factor | Dome |
Mounting Type | Ceiling |
Product colour | Black |
AC input voltage | 100 - 240 V |
Power consumption (typical) | 3.75 W |
Power source type | AC |
Power consumption (max) | 7.65 W |
DC output voltage | 9 |
DC output current | 0.85 A |
AC input frequency | 50 - 60 Hz |
Security algorithms | WPA2-PSK |
Operating relative humidity (H-H) | 10 - 90% |
Operating temperature (T-T) | -30 - 60 °C |
Storage temperature (T-T) | -40 - 60 °C |
Storage relative humidity (H-H) | 0 - 90% |
Reset button | Yes |
Width | 123.8 mm |
Height | 90 mm |
Depth | 123 mm |
Wi-Fi standards | Wi-Fi 4 (802.11n) |
Wi-Fi | Yes |
Channel bandwidth | 2400 MHz |
Networking standards | IEEE 802.11g |
Supported network protocols | TCP/IP, ICMP, DNS, HTTPS, TCP, UDP |
Ethernet LAN | Yes |
Bluetooth | No |
Certification | CE, FCC, RoHS, RCM |
Auto-tracking | Yes |
Type | IP security camera |
Placement supported | Indoor & outdoor |
Connectivity Technology | Wireless |
Mounting Kit | Yes |
Manual | Yes |
Mounting brackets included | Yes |
Number of Cameras | 1 |
Screws included | Yes |
Built-in microphone | Yes |
Built-in speaker(s) | Yes |
Card reader integrated | Yes |
COMPATIBLE MEMORY CARDS | MicroSD (TransFlash) |
Maximum memory card size | 512 GB |
Built-in HDD | No |
DC-in jack | Yes |
Lens viewing angle, horizontal | 360° |
Lens viewing angle, vertical | 130° |
Number of sensors | 1 |
Sensor type | CMOS |
Optical sensor size | 25.4 / 3 mm (1 / 3") |
Maximum Resolution | 2560 x 1440 pixels |
Supported graphics resolutions | 2560 x 1440 |
Frame rate | 30 fps |
Total megapixels | 4 MP |
Video formats supported | H.264 |
LED type | IR |
Night Vision | Yes |
Night vision distance | 30 m |
Infra-red wavelength | 850 nm |
Maximum aperture number | 1.61 |
Number of lenses | 1 |
Fixed focal length | 3.18 mm |
