Compliance certificates | CE |
Basic event | Motion Detection, Camera Tampering Detection, Exception |
Form factor | Dome |
Product colour | Black |
International Protection (IP) code | IP67 |
Housing material | Plastic |
I code | IK10 |
Mounting Type | Ceiling/wall |
Power source type | PoE |
Power consumption (max) | 5 W |
Mirror | Yes |
Active tampering alarm | Yes |
Digest authentication | Yes |
Video motion detection | Yes |
Intelligent Video Surveillance (IVS) system features | Human detection |
PASSWORD PROTECTION | Yes |
HTTPS encryption | Yes |
IP address filtering | Yes |
Operating temperature (T-T) | -30 - 60 °C |
Web-based management | Yes |
Management software | VIGI App, VIGI Security Manager, VIGI NVR |
Depth | 115 mm |
Package depth | 193 mm |
PACKAGE WEIGHT | 450 g |
Package height | 120 mm |
Width | 115 mm |
Height | 86 mm |
Package width | 153 mm |
Wi-Fi | No |
Ethernet interface type | Fast Ethernet |
Ethernet LAN | Yes |
Bluetooth | No |
Number of simultaneous live view channels | 3 channels |
Supported network protocols | TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS |
Certification | CE, BSMI, VCCI, ONVIF |
Type | IP security camera |
Connectivity Technology | Wired |
Day/night mode | Yes |
Placement supported | Indoor & outdoor |
Mounting Kit | Yes |
Number of Cameras | 1 |
Built-in HDD | No |
Ethernet LAN (RJ-45) ports | 1 |
Lens viewing angle, diagonal | 88.7° |
Lens viewing angle, horizontal | 75.1° |
Lens viewing angle, vertical | 41.5° |
Sensor type | CMOS |
Optical sensor size | 25.4 / 3 mm (1 / 3") |
Image quality adjustment | Saturation |
Supported graphics resolutions | 1280 x 720 (HD 720) |
Maximum Resolution | 2560 x 1440 pixels |
Video streaming | Yes |
Privacy masking | Yes |
Noise reduction technology | 3D noise reduction |
Video compression formats | H.265+ |
Frame rate | 30 fps |
Digital Wide Dynamic Range (DWDR) | Yes |
Bit rate | 64 Kbps - 4 Mbps |
Total megapixels | 4 MP |
Back Light Compensation (BLC) | Yes |
Highlight Compensation (HLC) | Yes |
Infra-red wavelength | 850 nm |
Night Vision | Yes |
LED type | IR |
Number of illumination LEDs | 1 |
Night vision distance | 30 m |
Lens diameter | 4 mm |
Number of lenses | 1 |
