Housing material | Metal |
Mounting Type | Wall |
International Protection (IP) code | IP67 |
Form factor | Bullet |
Product colour | White |
DC output voltage | 12 |
Power source type | DC |
Power consumption (max) | 10.1 W |
Privacy protection | Yes |
PASSWORD PROTECTION | Yes |
IP address filtering | Yes |
Digest authentication | Yes |
Operating temperature (T-T) | -30 - 60 °C |
Operating relative humidity (H-H) | 0 - 95% |
Storage temperature (T-T) | -40 - 60 °C |
Storage relative humidity (H-H) | 0 - 95% |
Depth | 236 mm |
Height | 99 mm |
Width | 102 mm |
Supported network protocols | TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS |
Ethernet interface type | Fast Ethernet |
Ethernet LAN | Yes |
Dynamic range | 120 dB |
Day/night mode | Yes |
Luminous Flux | 0.0005 lm |
Placement supported | Outdoor |
Wide Dynamic Range (WDR) | Yes |
Connectivity Technology | Wired |
Type | IP security camera |
Number of Cameras | 1 |
Signal-to-Noise Ratio (SNR) | 52 dB |
Built-in speaker(s) | Yes |
Bit rate range | 64 - 64 Kbit/s |
Sample Rate | 8 kHz |
Built-in microphone | Yes |
Ethernet LAN (RJ-45) ports | 1 |
Minimum illumination | 0.0005 lx |
Lens viewing angle, diagonal | 114.7° |
Camera shutter speed | 1/10000 s |
Lens viewing angle, horizontal | 95.2° |
Lens viewing angle, vertical | 50.6° |
Pan range | -90 - 90° |
Number of Privacy masking areas | 4 |
Tilt angle range | -90 - 90° |
Progressive Scan | Yes |
Sensor type | CMOS |
Optical sensor size | 25.4 / 1.8 mm (1 / 1.8") |
Video compression formats | H.264+ |
Noise reduction | Yes |
Noise reduction technology | 3D noise reduction |
Frame rate | 60 fps |
Region of Interest (ROI) encoding | Yes |
Privacy masking | Yes |
Total megapixels | 4 MP |
Maximum Resolution | 2688 x 1520 pixels |
Bit rate | 4 Mbps |
Supported graphics resolutions | 2048 x 1280 |
LED type | White |
Night Vision | Yes |
Number of illumination LEDs | 4 |
Night vision distance | 30 m |
Recognize distance | 14 m |
Detect distance | 70 m |
Observe distance | 29 m |
Focal length range | 4 mm |
Identify distance | 7 m |
Minimum aperture number | 1 |
Number of lenses | 1 |
Fixed focal length | 4 mm |
Maximum aperture number | 1 |
