International Protection (IP) code | IP67 |
Housing material | Metal |
Protection features | Waterproof |
Form factor | Turret |
Product colour | White |
Mounting Type | Ceiling |
Power source type | AC, PoE |
Human and vehicle targets classification | Yes |
Video motion detection | Yes |
Operating temperature (T-T) | -30 - 60 °C |
Storage temperature (T-T) | -40 - 60 °C |
Reset button | Yes |
Web browser | Yes |
Width | 111 mm |
Depth | 111 mm |
Weight | 480 g |
Height | 83.7 mm |
Ethernet LAN | Yes |
Supported network protocols | TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS |
Bluetooth | No |
Wi-Fi | No |
Dynamic range | 120 dB |
Infrared (IR) cut-off filter | Yes |
Connectivity Technology | Wired |
Type | IP security camera |
Day/night mode | Yes |
Placement supported | Indoor |
Wide Dynamic Range (WDR) | Yes |
Number of Cameras | 1 |
Sample Rate | 8 kHz |
Built-in speaker(s) | Yes |
Audio output channels | 1 channels |
Audio input channels | 1 channels |
Built-in microphone | Yes |
Voice Codecs | G.711alaw |
Built-in HDD | No |
Lens viewing angle, diagonal | 134° |
Lens viewing angle, horizontal | 111.4° |
Lens viewing angle, vertical | 58.8° |
Minimum illumination | 0.005 lx |
Tilt angle range | 0 - 85° |
Camera shutter speed | 1/3 - 1/10000 s |
Angle of rotation | 360° |
Pan range | 0 - 360° |
Number of Privacy masking areas | 4 |
Sensor type | CMOS |
Optical sensor size | 25.4 / 2.7 mm (1 / 2.7") |
Image quality adjustment | Saturation |
Back Light Compensation (BLC) | Yes |
Video formats supported | H.265+ |
Privacy masking | Yes |
Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
Total megapixels | 5 MP |
Region of Interest (ROI) encoding | Yes |
Maximum Resolution | 2880 x 1620 pixels |
Highlight Compensation (HLC) | Yes |
Infra-red wavelength | 850 nm |
Night vision distance | 30 m |
LED type | IR |
Night Vision | Yes |
Lens diameter | 2.8 mm |
Recognize distance | 13 m |
Fixed focal length | 2.8 mm |
Identify distance | 6 m |
Detect distance | 64 m |
Observe distance | 27 m |
Signal-to-Noise Ratio (SNR) (panoramic camera) | 52 dB |
